TRIO-PS/1AC/5DC/10 Phoenix Output power module

Phoenix Contact TRIO-PS/1AC/5DC/10 Overview

The Phoenix Contact TRIO-PS/1AC/5DC/10 is a compact and reliable single-phase input, DC output power supply unit belonging to Phoenix Contact's TRIO POWER series. This power supply series is specifically designed for standard industrial applications, featuring high efficiency and robustness.

Product Detailed Description

• Function:

• Converts single-phase AC input voltage into a stable 5 V DC output voltage.

• Provides an output current of up to 10 A.

• Features high efficiency, helping to reduce energy consumption and heat dissipation.

• Integrated overvoltage protection (OVP) safeguards connected loads against voltage spikes.

• Offers a power boost function to provide a higher output current for a short duration to handle starting loads.

• Utilizes screw connection terminals for easy wiring.

• Compact design saves space in control cabinets.

• Features:

• Single-phase AC input.

• Stable 5 V DC output.

• 10 A output current.

• High efficiency.

• Overvoltage protection (OVP).

• Power boost function.

• DIN rail mounting.

• Compact design.

• High reliability and long service life.

Product Parameters

• Input Voltage Range:

• 85 V AC to 264 V AC

• Input Frequency Range:

• 45 Hz to 65 Hz

• Output Voltage:

• 5 V DC ± 1%

• Output Current:

• 10 A

• Power Boost:

• 1.5 times the nominal current for 5 seconds

• Efficiency:

• Typ. > 90% (at 230 V AC input and full load)

• Overvoltage Protection (OVP):

• Output side > 6 V DC

• Connection Method:

• Screw connection

• Mounting Method:

• DIN rail NS 35

• Degree of Protection:

• IP20

• Ambient Temperature Range:

• -25 °C to +70 °C (derating may be required, refer to the datasheet)

• Dimensions (W x H x D):

• 45 mm x 130 mm x 125 mm

• Weight:

• Approx. 0.4 kg

• Certifications:

• CE, UL, cUL, EAC, etc. (refer to the specific product manual)

Product Advantages

• High Reliability:

• Phoenix Contact is a well-known manufacturer of industrial components, and their power supplies are known for their reliability.

• High Efficiency:

• Efficiency of over 90% helps to reduce energy consumption and heat dissipation.

• Power Boost Function:

• Capable of handling loads with high inrush currents.

• Overvoltage Protection:

• Protects connected devices from damage due to voltage spikes.

• Compact Design:

• Saves space in control cabinets.

• Easy Installation:

• DIN rail mounting and screw connection terminals make installation quick and easy.

• Wide Input Voltage Range:

• Suitable for different power systems worldwide.

Precautions

• Correct Selection:

• Ensure that the output voltage and current of the power supply meet the requirements of the load.

• Correct Installation:

• Follow Phoenix Contact's installation guidelines, ensuring the power supply is securely mounted and has adequate ventilation for cooling.

• Input Voltage:

• Verify that the input voltage is within the permissible range of the power supply.

• Grounding:

• Ensure that the ground terminal of the power supply is reliably grounded.

• Environmental Conditions:

• Avoid using the power supply in environments exceeding its operating temperature range.

• Derating:

• Derating may be necessary when operating at high ambient temperatures to ensure the lifespan and reliability of the power supply; refer to the datasheet.

Product Applications

• Automation Technology:

• Provides a stable 5 V DC power supply for automation components such as PLCs, sensors, and actuators.

• Control Systems:

• Used in various industrial control systems.

• Mechanical Engineering:

• Powers the control circuits of machines and equipment.

• Building Automation:

• Powers low-voltage devices in building control systems.

• Other Industrial Applications:

• Various applications requiring a stable 5 V DC power supply.
