Pilz PSS1DI2 safety input module

Product Detailed Description:

The Pilz PSS1DI2 is a safety input module designed for monitoring safety signals in machinery and plant control systems. It provides two independent safety inputs, typically configured for Normally Open (NO) contacts, allowing it to interface with various safety sensors such as emergency stop buttons, safety mats, light curtains, or safety door switches. The module is certified to meet the performance level PLe according to ISO 13849-1 and the safety integrity level SIL 2 according to IEC 61508. It features internal monitoring logic to detect certain types of faults (like short circuits or incorrect wiring) and ensure the integrity of the safety signal path before allowing it to influence the safety control system. Its compact design makes it suitable for integration into a wide range of control panels and applications where reliable safety signal acquisition is required.

Product Parameters:

• Number of Inputs: 2

• Input Type: Safety inputs, typically configured for Normally Open (NO) contacts (Check datasheet for potential alternative configurations like Normally Closed (NC) or PNP/NPN if available).

• Performance Level (PL): PLe (ISO 13849-1)

• Safety Integrity Level (SIL): SIL 2 (IEC 61508)

• Supply Voltage: Typically 24 V DC (Refer to datasheet for exact range and polarity requirements).

• Monitoring: Internal monitoring for fault detection (e.g., short circuit, polarity reversal, incorrect wiring).

• Output Signal: Provides a safe output signal (e.g., sinking or sourcing relay contact, or digital signal) to the connected safety controller or relay module, indicating the state of the safety input(s).

• Mounting: Usually DIN rail mountable.

• Environmental Ratings: Typically IP 20 (Refer to datasheet for specific temperature, humidity, and EMC ratings).

• Certifications: CE, UL, cULus, etc. (Refer to datasheet for specific certifications applicable to your region).

Product Advantages:

• High Reliability: Certified to PLe/SIL 2 standards, providing a high level of assurance for critical safety functions.

• Fault Detection: Internal monitoring helps detect potential wiring errors or component failures, enhancing overall system safety.

• Compact Design: Saves valuable space in control cabinets.

• Ease of Integration: Simple DIN rail mounting and standardized wiring facilitate quick installation into existing or new control systems.

• Flexibility: Can interface with a wide variety of standard safety sensors commonly used in industrial applications.

• Reduces Wiring: Can sometimes simplify wiring compared to discrete safety components by consolidating input monitoring functions.

Precautions / Important Notes:

• Correct Wiring is Crucial: Incorrect wiring can lead to safety failures. Always follow the specific wiring diagrams provided in the official Pilz documentation for the PSS1DI2.

• Polarity: Ensure correct power supply polarity is applied. Most safety modules are polarity-sensitive.

• Sensor Compatibility: Verify that the connected safety sensors are compatible with the input type (NO, NC, PNP/NPN) configured on the PSS1DI2 module.

• Environmental Conditions: Install the module within the specified environmental limits (temperature, humidity, vibration) to ensure reliable operation.

• Certification Compliance: Ensure the module’s certifications (CE, UL, etc.) are appropriate for the intended application and region.

• Read Documentation: Thoroughly read and understand the user manual and datasheet before installation and operation.

• Qualified Personnel: Installation, configuration, and maintenance should only be performed by qualified personnel familiar with safety control systems.

Product Applications:

The Pilz PSS1DI2 is used in a wide range of applications where reliable monitoring of safety sensors is essential:

• Machine Tools: Monitoring emergency stops, safety guards, and presence detection sensors.

• Robotics: Ensuring safe operation by monitoring emergency stops, light curtains, and robot cell access doors.

• Packaging Machinery: Verifying the status of safety devices on conveyors, filling stations, and packaging units.

• Material Handling: Monitoring safety sensors on automated guided vehicles (AGVs), lifts, and conveyors.

• Plants and Installations: Used in control systems for chemical plants, water treatment facilities, or power generation where safe shutdown or interlocking is required.

• General Industrial Automation: Any application requiring the reliable connection and monitoring of standard safety sensors to a safety controller or relay system according to PLe/SIL 2 standards.
