RELIANCE WR-D4007 power supply module

RELIANCE WR-D4007 Overview

The RELIANCE WR-D4007 is an industrial-grade power supply module designed to provide reliable electrical power to control components within automation and motion control systems. It is part of the Reliance Electric product line, known for its robust and precise industrial equipment.

Product Detailed Description

• Function: The WR-D4007 serves as a power supply card, converting incoming AC power to the necessary DC voltage required by various components within a PLC (Programmable Logic Controller) or other industrial control systems, particularly for the PSC5000 series. It ensures a stable and consistent power output for connected devices. It also incorporates filtering to protect sensitive equipment from electrical interference.

• Features:

• Compact, industrial-grade design.

• Robust power delivery for system reliability.

• Designed to withstand harsh industrial environments and vibrations.

• Precise output voltage and current ratings.

• Efficient power conversion.

• Reliable power distribution to multiple devices.

• Noise reduction capabilities.

• Often found as a "Power Supply Card II" or "PSC Power Supply II MCPS2".

• Discontinued by Manufacturer: This product is no longer actively manufactured by Reliance Electric/Rockwell Automation.

Product Parameters

Based on the search results, the key parameters for the RELIANCE WR-D4007 are:

• Product Type: Power Supply Card / Power Supply Module

• Input Voltage: 85-132V AC

• Output Voltage: 24V DC (Max)

• Output Current: 5A (Max)

• Input Frequency: 47-63Hz

• Dimensions (approx.): 936 x 605 x 596 mm (Note: One source lists this, but another lists Height: 215 mm, Length: 250 mm, Width: 55 mm, Weight: 1.5 kg. The latter seems more plausible for a "card" or "module". Always verify with actual product or a reliable source.)

• Weight (approx.): 2.1 kg (Another source lists 1.5 kg).

• Compatibility: Designed for use with Reliance Electric PLC systems, specifically mentioned for PSC5000.

• Condition (Typically found as): Used, refurbished, or new old stock (due to discontinuation).

Product Advantages

• Reliable Power Delivery: Provides stable and consistent power output, crucial for the reliable operation of sensitive control components.

• Industrial Durability: Built to withstand demanding industrial environments, including potential vibrations.

• Precise Output: Delivers specific voltage and current ratings to match the exact requirements of connected equipment.

• Noise Reduction: Helps protect sensitive electronics from electrical interference, contributing to system stability.

• Compatibility: Designed to integrate seamlessly with Reliance Electric's automation and motion control systems, particularly the PSC5000 series.

Precautions

• Discontinued Product: As it's discontinued, finding new units can be challenging, and support from the original manufacturer may be limited. Sourcing from reputable industrial surplus suppliers is crucial.

• Verification: Always verify the specific input/output requirements of your system against the specifications of the WR-D4007 before purchase and installation.

• Installation: Follow proper industrial electrical installation procedures. Ensure correct wiring for input AC and output DC connections, and proper grounding.

• Environmental Conditions: While designed for industrial environments, ensure the operating environment (temperature, humidity, vibration) is within the component's specified limits (if available in a detailed manual).

• Compatibility with Existing System: Confirm full compatibility with your existing Reliance Electric or Rockwell Automation system, especially if replacing a faulty unit.

• Warranty: Third-party suppliers often offer their own warranties (e.g., 3 months to 2 years) since the factory warranty may no longer apply.

Product Applications

The RELIANCE WR-D4007 is primarily used in industrial automation and motion control systems where Reliance Electric components are deployed. Its specific applications include:

• PLC Systems: Providing power to various modules within Reliance Electric PLCs, particularly the PSC5000 series.

• Industrial Automation Systems: Powering control components for various automated processes.

• Motion Control Systems: Ensuring stable power for components involved in motor control and other motion-related applications.

• General Industrial Control: Any application requiring a reliable 24V DC power source within an industrial control panel or cabinet.
