BMXXCAUSBH045 SCHNEIDER

In order to determine the number of shots required; the first factor is the ability for the circuit breaker to perform several trip-close operations in a short time and, the effect of these operations on the maintenance period.

Description:

Application

Software Setup

Setting-up a Hot Standby application requires configuring four dialogs, and

configuring must occur during the initial setup.

Schneider Electric recommends

Non-Transfer

Area

A "Non Transfer Area" may be specified by means of a starting %MW reference field

and a length field.

This "Non-Transfer Area" defines a portion of the output registers’ (%MW) State

RAM. This defined portion (the referenced positions of data memory) will not be

transferred from Primary to Standby at each scan cycle.

A null start value is an illegal entry, as %MW0 does not exist on Quantum.

Option Set Description

Run Mode Online for Controller A

and B

After the project download, controllers A and

B are coupled together, therefore, building

an effective redundant system.

Invalidate Keypad Check box NOT

checked

Control the redundant state through both the

Control Register bit and keypad entries.

Stand By on Logic

Mismatch

Online The redundant system acts as a Primary /

Standby system, even if a modification was

made to one of the controllers’ project.

Swap Address At

Switchover

Modbus Port 1

Check box checked A 128 offset is added to the Standby unit's

slave Modbus port address.
