Schneider TCCX1730LW Operator Panel

AEG Schneider TCCX1730LW Operator Panel Overview

The AEG Schneider TCCX1730LW is part of the CCX 17 series of operator panels, which were compact Human-Machine Interface (HMI) systems. Designed for machine or process level applications, this model features a backlit LCD display and provides interactive control and monitoring capabilities, primarily connecting to Telemecanique and Modicon PLCs.

Product Detailed Description

• Functionality:

• Displaying Messages and Variables: Provides a visual interface to display messages, process variables, and status information from connected PLCs.

• Interactive Control: Allows operators to interact with the control system through function keys located on either side of the display. These keys are typically assigned commands related to the on-screen messages.

• Parameter Modification: Features a numeric keypad with additional function keys for entering values and modifying parameters within the PLC program.

• Operating Incident Recording: The operator panel can store a record of failures or operating incidents with their time and date, which can be printed out as a continuous log if a printer is connected.

• Key Features:

• LCD Display: Features a backlit LCD display, offering clear and detailed visual output. The "L" in the model name (TCCX 17 30 L) signifies an LCD display.

• Compact Design: Designed to be space-efficient for integration into control panels.

• Dedicated Function Keys: Physical function keys for direct command selection.

• Numeric Keypad: For data entry and parameter changes.

• PLC Connectivity: Primarily designed to connect with Telemecanique Series 7, APRIL Series 1000, and TSX Modicon Nano/Micro/Premium PLCs (e.g., TSX 7 Model 40, TSX 17, TSX 07 nano-PLCs).

• Communication Protocols: Supports UNI-TELWAY bus/interface for communication with compatible PLCs.

• Durable Construction: Built to withstand industrial conditions, ensuring long-term reliability and performance.

• Adjustable Brightness/Contrast: Allows for adjustment of LCD display contrast for optimal viewing.

• Mounting: Designed with adjustable locking clips for panel mounting, accommodating various panel thicknesses.

Product Parameters

(Note: As an older model, specific detailed parameters can be harder to find. The following are typical for the CCX 17 30 L series.)

• Display Type: Backlit LCD

• Display Size: Typically around 8.4 inches (based on similar models in the series).

• Resolution: High-resolution LCD for its generation, providing clear visuals.

• Input Method: Function keys and numeric keypad.

• Connectivity: UNI-TELWAY bus/interface (RS232 or RS485 physical layer depending on the specific interface/cable).

• Supported PLCs: Telemecanique Series 7, APRIL Series 1000, TSX Modicon Nano/Micro/Premium PLCs (e.g., TSX 7 Model 40, TSX 17, TSX 07 nano-PLCs).

• Power Supply: Typically 24 VDC (common for industrial HMI panels).

• Enclosure Rating: Designed for industrial environments, likely IP65 (front panel) for dust and splash protection.

• Mounting: Panel mount with adjustable clips.

• Operating Temperature: Standard industrial range, typically 0°C to +50°C.

Product Advantages

• Reliable Industrial HMI: Built for rugged industrial environments, ensuring consistent performance.

• Direct PLC Compatibility: Designed for seamless integration with a specific range of popular Telemecanique and Modicon PLCs, simplifying system setup.

• Intuitive Operator Interface: Function keys and a numeric keypad offer direct and tactile control, which can be preferred by operators in certain industrial settings.

• Local Data Logging: The ability to record operating incidents with time and date provides valuable diagnostic information for troubleshooting.

• Compact Size: Its small form factor makes it suitable for integration into machine control panels where space is limited.

Precautions

• Compatibility: Ensure the HMI is compatible with your specific PLC model and communication protocol (UNI-TELWAY).

• Programming Software: These older panels require specific legacy programming software (likely from Schneider Electric/Telemecanique's historical range) for configuration, which may be challenging to acquire or run on modern operating systems.

• Power Supply: Use a stable and correctly rated 24 VDC power supply.

• Environmental Conditions: Install within the specified operating temperature and humidity ranges. Ensure proper sealing for panel mounting to maintain its IP rating.

• Wiring: Follow the wiring diagrams in the manual meticulously for power and communication connections.

• Obsolescence/Support: As an older product, direct factory support from Schneider Electric may be limited, and spare parts might be difficult to source. Consider this for long-term maintenance and new projects.

Product Applications

The TCCX1730LW was primarily used in applications requiring local operator control and monitoring for machines and small processes.

• Machine Control:

• Packaging machines

• Textile machinery

• Material handling equipment (e.g., small conveyors)

• Special-purpose machinery

• Process Control:

• Local control stations for small-scale batch processes.

• Monitoring of specific process variables in discrete manufacturing.

• Building Automation:

• Simple control panels for HVAC systems or access control points (less common, but possible).

• OEM Applications:

• Integrated into control panels of machinery supplied by original equipment manufacturers.
