Schneider TSXMFP032P PLC Module

Schneider Modicon TSX Micro TSXMFP032P Overview

The Schneider Modicon TSX Micro TSXMFP032P is a compact Programmable Logic Controller (PLC) belonging to the TSX Micro series. It provides a control solution for small to medium-sized automation applications.

Product Detailed Description

• Function:

• Executes logic control programs to automate industrial processes and machines.

• Receives signals from input devices, processes them according to user-defined programs, and controls output devices.

• Provides real-time control and sequential control functions.

• Supports multiple programming languages such as Ladder Diagram, Instruction List, Function Block Diagram, etc. (depending on the programming software).

• Features integrated Digital Input and Output (I/O) channels.

• Offers communication interfaces for communication with HMIs (Human Machine Interfaces), other PLCs, or supervisory systems.

• Features:

• Compact design, saving installation space.

• Integrated 32 digital I/O points (16 inputs, 16 outputs).

• Integrated power supply.

• Integrated Modbus RTU and Modbus ASCII serial communication port.

• Expandable I/O points and communication capabilities via expansion modules.

• Programmed using Telemecanique PL7 Junior or PL7 Pro programming software.

• DIN rail mounting.

Product Parameters

• Model: TSXMFP032P

• Product Line: Modicon TSX Micro

• CPU Type: Micro PLC

• Digital Inputs: 16 channels, 24 V DC

• Digital Outputs: 16 channels, 24 V DC, transistor outputs (sink/source configurable)

• Power Supply: 24 V DC

• Programming Languages: Ladder Diagram, Instruction List, etc. (depending on the programming software)

• Communication Ports:

• 1 x Modbus RTU/ASCII (RS-485)

• Program Memory Capacity: Approx. 128 KB

• Data Memory Capacity: Approx. 64 KB

• Scan Cycle: Typically a few milliseconds to tens of milliseconds, depending on program complexity

• Expansion Capability: Expandable I/O and communication via TSX Micro expansion modules

• Mounting: DIN rail mounting

• Protection Rating: IP20

• Operating Temperature: 0 °C to +55 °C

• Dimensions (W x H x D): Refer to the specific product manual

• Weight: Refer to the specific product manual

• Certifications: CE, UL, cUL, CSA, etc. (refer to the specific product manual)

Product Advantages

• Compact Design: Saves control cabinet space.

• Integrated I/O: Suitable for small applications, reducing additional hardware costs.

• Easy Programming: Uses Schneider Electric's well-established programming software.

• High Reliability: Suitable for industrial environments.

• Communication Capabilities: Integrated Modbus interface for easy communication with other devices.

• Scalability: Expandable via expansion modules to meet more complex application needs.

• Cost-Effective: Provides an economical control solution for small to medium-sized applications.

Precautions

• Correct Installation: Follow Schneider Electric's installation guidelines, ensuring the PLC is securely mounted and correctly wired.

• Power Requirements: Use a 24 V DC power supply that meets the specifications.

• Environmental Conditions: Ensure the operating environment temperature and humidity are within the permissible range, and avoid dust, corrosive gases, and strong vibrations.

• Programming Software: Requires Telemecanique PL7 Junior or PL7 Pro programming software for program development, downloading, and monitoring (license may be required).

• I/O Wiring: Carefully check the wiring of input and output devices to ensure correct connections.

• Grounding: Ensure the PLC system is properly grounded to prevent electromagnetic interference and ensure safety.

• Maintenance: Regularly inspect the PLC and its connections to ensure proper operation.

Product Applications

• Small Machine Control: E.g., small packaging machines, labeling machines, conveyor belt control.

• Building Automation: E.g., lighting control, HVAC system control.

• Water Treatment: E.g., control of small water pumping stations.

• Material Handling: E.g., control of simple automated warehouse systems.

• OEM Applications: Integration into various small automated equipment.
