Toshiba VFMB1-4004PL Output module

Toshiba VFMB1-4004PL Overview

The Toshiba VFMB1-4004PL is a general-purpose inverter belonging to the Toshiba VF-MB1 series. This series of inverters is primarily used to control pumps and fans, and can also be used for drive control of machine tools, conveyors, extruders, mixers, multi-motor installations, gears, and even lifting equipment.

Product Detailed Description

• Function:

• Controls the speed and torque of AC motors.

• Provides multiple control modes, including scalar (U/f) control and vector control.

• Built-in RS485 communication interface, supporting ModBus RTU protocol.

• Optional network protocols such as DeviceNet, PROFIBUS DP, CC-Link, EtherNet/IP, Modbus TCP, EtherCAT, CANopen.

• Smoke alarm function suitable for ventilation systems.

• Built-in EMI filter (EMC), compliant with European EMC Directive IEC/EN 61800.

• Built in dynamic braking (brake chopper).

• Safe Torque Off (STO) function, compliant with international standards (EN/IEC 61508, EN954-1, ISO 13849-1).

• Features:

• "Slim shape" housing, compact and easy to install.

• Advanced control system, capable of controlling asynchronous motors and permanent magnet motors.

• "Auto-tuning" function, automatically determines motor parameters.

Product Parameters

• Specific parameters may vary according to the Toshiba official product manual and the specific configuration of the inverter.

• According to the information, the VF-MB1 series has the following characteristics.

• Overcurrent: 150% - 60 seconds, 200% - 0.5 seconds.

• Built-in RS485 interface, ModBus RTU protocol and Toshiba protocol (up to 38.4kbps).

Product Advantages

• Compact Design:

• Saves installation space.

• Versatility:

• Suitable for a wide range of industrial applications.

• Advanced Control Technology:

• Improves motor control accuracy and efficiency.

• Rich Communication Interfaces:

• Facilitates integration into various automation systems.

• Safety Functions:

• Ensures the safety of operators and equipment.

Precautions

• Correct Installation:

• Install and wire according to the requirements of the product manual.

• Environmental Conditions:

• Ensure that the working environment meets the product specifications.

• Maintenance:

• Regularly inspect and maintain the inverter for optimal performance.

• Electrical Safety:

• Pay attention to high voltage hazards.

Product Applications

• Pump and Fan Control:

• Machine Tool Control:

• Conveyor Control:

• Extruder Control:

• Mixer Control:

• Ventilation Systems:

• Lifting Equipment:
