Product Description
The Woodward EASYGEN-2500-5 is a state-of-the-art genset control and paralleling system designed for managing single or multiple generator sets in a wide range of power generation applications. The 8440-1884 model is a specific configuration variant of the EASYGEN-2500 series, offering advanced load sharing, synchronization, and protection features for critical power systems. It is ideal for use in both standby and prime power applications, ensuring reliable and efficient operation of diesel or gas-powered generator sets.
Product Specifications
| Parameter | Specification |
|---|
| Model Number | 8440-1884 EASYGEN-2500-5 |
| Input Voltage | 8–36 VDC |
| Operating Temperature | -30°C to +70°C |
| Communication Protocols | Modbus RTU, CANopen, J1939, M-Link |
| Number of Digital Inputs | 16 |
| Number of Digital Outputs | 8 (relays) |
| Analog Inputs | 8 (configurable for voltage, current, thermocouple) |
| Analog Outputs | 4 (0–20 mA or 0–10 V) |
| Display | 5.7-inch color LCD touchscreen |
| Protection Features | Over/under voltage, over/under frequency, reverse power, overcurrent, etc. |
| Enclosure Rating | IP54 (front panel) |
| Certifications | UL, CE, CSA, DNV, ABS, Lloyd’s Register |
Product Advantages
Advanced Paralleling Capability: Supports up to 32 gensets in parallel with automatic load sharing and synchronization.
Flexible Communication: Multiple protocols allow seamless integration with SCADA, PLCs, and other control systems.
User-Friendly Interface: Intuitive touchscreen display simplifies configuration, monitoring, and diagnostics.
Robust Protection: Comprehensive protection features safeguard gensets and connected loads from electrical faults.
High Reliability: Designed for harsh industrial environments with wide temperature tolerance and durable construction.
Remote Monitoring: Enables remote access and control via Ethernet or serial communication.
Multi-Application Support: Suitable for standby, prime, and peak shaving power applications.
Precautions
Installation: Must be installed by qualified personnel familiar with genset control systems and electrical safety standards.
Wiring: Ensure correct wiring of all inputs and outputs to avoid malfunction or damage. Follow the provided wiring diagrams.
Configuration: Properly configure the module according to the specific genset and application requirements using the EASYGEN-2500 configuration software.
Environmental Protection: Although the unit is rugged, avoid exposure to extreme moisture, dust, or corrosive environments beyond its IP54 rating.
Firmware Updates: Regularly check for firmware updates to ensure optimal performance and security.
Maintenance: Periodically inspect the unit for signs of wear, damage, or loose connections.
Product Applications
Data Centers: Provides reliable backup power and ensures seamless transfer during utility outages.
Hospitals: Ensures uninterrupted power for critical medical equipment and life support systems.
Telecommunications: Maintains power continuity for base stations and communication hubs.
Industrial Plants: Supports critical processes in manufacturing, oil & gas, and mining operations.
Marine and Offshore: Used in shipboard power systems and offshore platforms for reliable power generation.
Commercial Buildings: Integrates into building management systems for emergency power and load management.
Renewable Energy: Supports hybrid power systems combining gensets with solar or wind power.
