HONEYWELL FC-TSPKUNI-1624 Process Controller Module

Honeywell FC-TSPKUNI-1624 Overview

The Honeywell FC-TSPKUNI-1624 is a Universal Process Controller module belonging to Honeywell's Safety Manager series. It is designed for safety-critical applications, providing flexible and configurable control and safety functions. The "UNI" designation indicates its universality, meaning it can be configured for various input/output types.

Product Detailed Description

• Function:

• Executes safety-related control logic.

• Processes safety input signals from field devices.

• Generates safety output signals to drive final elements (e.g., valves, actuators, relays).

• Supports multiple Input/Output (I/O) types that can be configured via software.

• Integrated diagnostics for monitoring the health of the module and field devices.

• Communicates with other Safety Manager modules and system components via the safety network.

• Features:

• Universal I/O channels that can be software-configured as Digital Input (DI), Digital Output (DO), Analog Input (AI), or Analog Output (AO).

• High reliability and availability for SIL (Safety Integrity Level) applications.

• Integrated safety functions compliant with relevant safety standards such as IEC 61508.

• Configurable fail-safe states.

• Supports Online Replacement.

• Powerful processing capability for executing complex safety logic.

Product Parameters

As the FC-TSPKUNI-1624 is a configurable module, its specific parameters depend on its software configuration. The following are some typical parameters for Safety Manager Universal Process Controller modules. Always refer to the official datasheet for the specific model for accurate parameters:

• Number of Channels:

• 16 channels (indicated by "16" in the model name).

• Configurable I/O Types:

• Digital Input (DI): 24 V DC, compliant with IEC 61131-2 Type 1.

• Digital Output (DO): 24 V DC, up to a certain current rating (specific value depends on configuration).

• Analog Input (AI): e.g., 4-20 mA, HART compatible.

• Analog Output (AO): e.g., 4-20 mA, HART compatible.

• Safety Integrity Level (SIL):

• Typically supports SIL 2 or SIL 3 (depending on configuration and system certification).

• Supply Voltage:

• Typically 24 V DC.

• Power Consumption:

• Specific value depends on configuration.

• Operating Temperature:

• Typically in the range of -40 °C to +70 °C.

• Protection Degree:

• Typically IP20.

• Communication Interfaces:

• Safety Manager safety network interface.

• May include other diagnostic or configuration interfaces.

• Dimensions and Weight:

• Specific values depend on the module design.

Product Advantages

• High Versatility:

• A single module can be configured for multiple I/O types, reducing spare parts inventory and engineering complexity.

• High Safety:

• Specifically designed for safety-critical applications, compliant with relevant safety standards.

• High Reliability and Availability:

• Redundancy options and online replacement functionality ensure high system availability.

• Flexible Configuration:

• I/O types and safety functions can be configured via software to adapt to different application needs.

• Powerful Diagnostics:

• Enables quick identification and troubleshooting of faults, improving system maintenance efficiency.

• Easy Integration:

• Seamless integration with other modules and system components of the Honeywell Safety Manager series.

Precautions

• Correct Configuration:

• Proper configuration of I/O types and safety parameters must be performed using Honeywell's safety configuration tools.

• Safety Design:

• Integrate this module into an overall safety system that complies with relevant safety standards.

• Correct Installation:

• Follow Honeywell's installation guidelines, including proper wiring and environmental requirements.

• Power Requirements:

• Use a power supply that meets the specifications.

• Environmental Conditions:

• Ensure the operating environment temperature and humidity are within the permissible range.

• Regular Maintenance and Testing:

• Perform regular maintenance and functional tests as recommended by Honeywell to ensure the effectiveness of safety functions.

• Electrostatic Discharge (ESD) Precautions:

• Take appropriate ESD precautions during handling and installation.

Product Applications

The Honeywell FC-TSPKUNI-1624 or similar Universal Safety Process Controller modules are widely used in various safety-critical industrial sectors, including but not limited to:

• Oil and Gas:

• Emergency Shutdown Systems (ESD).

• Fire and Gas Detection Systems (F&G).

• High Integrity Pressure Protection Systems (HIPPS).

• Chemical:

• Process Safety Systems (PSS).

• Interlock Systems.

• Power Generation:

• Boiler Protection Systems.

• Turbine Protection Systems.

• Pharmaceutical:

• Safety Interlocking and Control.

• Other Safety-Critical Applications:

• Any industrial field requiring compliance with SIL levels.
