Siemens 6AV2124-0JC01-0AX0 Touch screen panel

Siemens SIMATIC HMI TP1200 Comfort (6AV2124-0JC01-0AX0) Overview

The Siemens SIMATIC HMI TP1200 Comfort is an advanced Human Machine Interface (HMI) touchscreen panel belonging to the SIMATIC HMI Comfort Panel series. It offers high performance, high functionality, and a user-friendly operating interface for various industrial automation applications.

Product Detailed Description

• Function:

• Visualization of machine and plant processes.

• Operator control and monitoring of machines and equipment.

• Display of process data, alarms, and trends.

• Communication with PLCs (Programmable Logic Controllers) and other automation components via various interfaces.

• Supports recipe management and data logging.

• Features:

• 12-inch widescreen TFT color touch display.

• High resolution for clear and easy-to-read visualization.

• High-performance processor for fast screen changes and smooth operation.

• Integrated PROFINET/Ethernet interface.

• Supports multiple communication protocols.

• IP65 protection rating (front) for industrial environments.

• User-friendly WinCC Comfort engineering software for configuration.

• Integrated functions such as alarm management, trend control, recipe management, and user management.

Product Parameters

• Display:

• Size: 12 inches

• Type: TFT Color LCD

• Resolution: 1280 x 800 pixels (widescreen)

• Touchscreen: Analog-resistive

• Backlighting: LED

• Power Supply:

• Rated Voltage: 24 V DC

• Interfaces:

• PROFINET/Ethernet (1 x RJ45)

• USB (2 x USB 2.0, Type A)

• RS 422/485 (optional, via interface module)

• Memory:

• User-available memory: approx. 12 MB

• Degree of Protection:

• Front: IP65

• Rear: IP20

• Ambient Temperature:

• Operating temperature: 0 °C to +50 °C

• Storage temperature: -20 °C to +60 °C

• Mounting Type:

• Panel mounting

• Dimensions (W x H x D):

• 336 mm x 250 mm x 59 mm

• Weight:

• Approx. 2.1 kg

• Engineering Software:

• WinCC Comfort (included in STEP 7 TIA Portal)

Product Advantages

• High Performance:

• Powerful processor and sufficient memory ensure smooth operation and fast response times.

• Clear Visualization:

• High-resolution widescreen display provides clear and detailed process information.

• User-Friendliness:

• Intuitive touch operation and powerful WinCC Comfort engineering software simplify development and operation.

• Strong Communication Capabilities:

• Integrated PROFINET/Ethernet interface and support for multiple protocols facilitate integration into various automation systems.

• Industrial Suitability:

• Robust design and IP65 protection rating (front) make it suitable for harsh industrial environments.

• Rich Functionality:

• Integrated alarm management, trend control, recipe management, and user management functions meet various application needs.

Precautions

• Correct Installation:

• Follow Siemens' installation guidelines to ensure the panel is securely mounted and correctly wired.

• Power Requirements:

• Ensure the use of a 24 V DC power supply that meets the specifications.

• Environmental Conditions:

• Avoid using the device outside the specified ambient temperature and humidity ranges.

• Engineering Configuration:

• Use WinCC Comfort software for proper project configuration and programming.

• Electrostatic Discharge (ESD) Protection:

• Take appropriate ESD protection measures during operation and installation.

Product Applications

• Factory Automation:

• Machine control and monitoring.

• Production line visualization.

• Process Automation:

• Monitoring and control of process parameters.

• Alarm and event management.

• Building Automation:

• HVAC control and monitoring.

• Energy management systems.

• Other Industrial Applications:

• Any field requiring human-machine interaction for monitoring and controlling industrial processes.
