Yokogawa PS65*A Programmable controller

Product Detailed Description

• Functionality:

• Measurement and Display: Accurately measure process variables from various sensors (thermocouples, RTDs, mV, V, mA inputs) and display them clearly on an integrated LCD.

• Control Modes: Implement a variety of control algorithms including PID control, ON/OFF control (with hysteresis), two-position two-level control, heating/cooling control, and position proportional control for actuators. Many models support single-loop, dual-loop, and cascade control.

• Alarm Functions: Offer multiple alarm types such as measured value (PV) high/low limit alarms, deviation alarms, rate-of-change alarms, setpoint alarms, and output alarms (e.g., heater burnout alarm with optional /HA).

• Computation Functions: Include signal computation features like bias, filter, PV tracking, square root extraction, and multi-segment linearizers.

• Ladder Sequence Control: Many models incorporate a built-in ladder sequence function, allowing for simple logic control similar to PLCs, reducing the need for external devices and wiring.

• Communication: Support various communication protocols for integration into larger control systems (e.g., Modbus RTU, Modbus TCP/IP (Ethernet), PROFIBUS-DP, CC-Link, DeviceNet).

• Recipe Management: Enable the storage and execution of different control recipes.

• Features:

• Easy-to-read Displays: Utilize 14-segment color LCDs (e.g., active color PV display) with large characters and intuitive navigation guides and keys for enhanced usability and clear status indication.

• Universal Inputs/Outputs: Standard universal I/O flexibility supports a wide range of sensor types and controlled devices.

• Compact Design: Short depth (e.g., 65mm for some models) helps save instrument panel space.

• Robust Construction: Designed for industrial environments with dust and waterproof front panels (e.g., IP66/NEMA 4 compliant).

• Auto-tuning: Simplifies PID parameter tuning for optimal control performance.

• Software Support: Often supported by PC-based parameter setting software (e.g., LL50A) for easier configuration and data management.

• Security: Password protection to prevent unauthorized parameter changes.

Product Parameters (General, as specific models vary)

• Display: 14-segment color LCD (active color PV display)

• Input Types: Universal inputs for thermocouples (TC), RTDs, mV, V, mA, voltage pulse, relay contact.

• Output Types: Relay, voltage pulse, current output (e.g., 4-20 mA DC), motor operated valve control (position proportional).

• Control Interval: Varies by model (e.g., 50ms, 100ms, 200ms).

• Power Supply: Typically 100-240 V AC or 24 V AC/DC.

• Accuracy: High precision, often around ±0.1% of F.S.

• Communication Protocols: Modbus RTU (RS-485), Modbus TCP (Ethernet), PROFIBUS-DP, CC-Link, DeviceNet.

• Ladder Program Capacity: Varies by model (e.g., 300 steps, 500 steps, 1000 steps).

• Program Patterns: Up to 99 patterns (for program controllers like UP series), with varying segments per pattern.

• Ambient Temperature: Typically 0 to 50°C (with variations for side-by-side mounting).

• Ambient Humidity: 5 to 95% RH (no condensation).

• Protection Level (Front Panel): IP66/NEMA 4.

• Mounting: Panel mount (e.g., 1/8 DIN, 1/4 DIN).

• Certifications: CE, UL/cUL, KCC, EAC, RoHS/WEEE compliant (varies by model).

Product Advantages

• Enhanced Usability: Bright, easy-to-read displays and intuitive navigation keys simplify operation and configuration, reducing operator errors.

• High Performance Control: Advanced PID control algorithms, auto-tuning, and specialized control functions (e.g., SUPER for overshoot suppression) ensure precise and stable process control.

• Cost-Effective: Built-in ladder sequence function and universal I/O often eliminate the need for peripheral devices and associated wiring, reducing overall system cost.

• Flexibility and Versatility: Wide range of input/output types, control modes, and communication options make them adaptable to diverse applications and integration into various control systems.

• Space-Saving: Compact dimensions allow for efficient panel mounting.

• Robust and Reliable: Designed for harsh industrial environments, ensuring long-term stable operation.

• Simplified Engineering: PC-based software tools and clear documentation streamline parameter setting and data management.

Precautions

• Installation:

• Mount in a well-ventilated location to prevent internal temperature rise.

• Avoid locations with strong mechanical vibration, direct sunlight, or close to heaters.

• Ensure terminals are not inadvertently touched and that the instrument is horizontally leveled.

• Install in locations with stable temperatures (ideally around 23°C).

• Avoid locations with substantial amounts of oily fumes, steam, moisture, dust, or corrosive gases.

• Do not mount directly on flammable surfaces.

• Electrical Safety:

• Do not operate in explosive atmospheres or near strong electromagnetic field-generating sources.

• Only Yokogawa service personnel should remove internal units or replace fuses due to high voltage parts.

• Observe all safety precautions described in the user's manual (e.g., warnings for electric shock).

• Wiring:

• Ensure proper wiring and grounding according to the provided manuals.

• Parameter Setting:

• Carefully refer to parameter maps and lists in the manual, as some parameters may not be displayed depending on the model and suffix codes.

• Utilize password protection to prevent unintentional parameter changes.

• Maintenance:

• Regularly check the instrument for any signs of damage or malfunction.

• Refer to the user's manual for recommended maintenance procedures.

Product Applications

Yokogawa Digital Indicating Controllers are extensively used in various industrial applications for measurement, display, and control, including:

• Industrial Furnaces: Controlling temperature in heat treatment processes, kilns, and ovens.

• HVAC Systems: Temperature, humidity, and pressure control in heating, ventilation, and air conditioning units.

• Refrigeration Systems: Temperature and pressure control in chillers, freezers, and cold storage.

• Plastics and Rubber Industry: Temperature control for extruders, injection molding machines.

• Food and Beverage: Temperature control in cooking, pasteurization, and sterilization processes.

• Pharmaceutical Industry: Precise temperature and process control in drug manufacturing.

• Semiconductor Manufacturing: Critical temperature and environmental control in cleanrooms and process equipment.

• Water Treatment: pH, flow, and level control in water purification and wastewater treatment plants.

• Packaging Machinery: Temperature control for sealing, heating, and other processes.

• Research and Development: Accurate control of experimental parameters in laboratories.

• Other General Process Control: Any application requiring precise single or multi-loop control of process variables.
