ABB DP820 Dual Channel HART/PA Adapter

ABB DP820 Overview

The ABB DP820 is a dual Ethernet interface module that is part of the ABB Freelance Distributed Control System (DCS). It provides connectivity for the Freelance system to Ethernet networks for communication, data exchange, and system integration.

Product Detailed Description

• Function:

• Provides two independent Ethernet interfaces.

• Supports various Ethernet protocols for communication with supervisory systems, engineering tools, other control systems, or network devices.

• Enables data acquisition, monitoring, and remote access for the Freelance control system.

• Supports redundant Ethernet connections for increased communication reliability and availability (depending on the specific configuration).

• Integrates into the Freelance control network for data exchange with other Freelance controllers and I/O modules.

• Features:

• Dual-channel design offering flexible network connection options.

• Supports multiple communication protocols such as TCP/IP, UDP, etc.

• High-speed Ethernet interfaces ensuring fast data transmission.

• Robust industrial design suitable for harsh industrial environments.

• Easy integration into the Freelance system.

Product Parameters

As there may be different versions or configurations of the ABB DP820, the following are some typical parameters. Always refer to the official datasheet for the specific model:

• Number of Interfaces:

• 2 Ethernet interfaces (RJ45 connectors)

• Ethernet Standard:

• 10/100 Mbit/s (may support higher speeds depending on the specific model)

• Supported Protocols:

• TCP/IP

• UDP

• Modbus TCP

• Ethernet/IP (may be supported depending on the specific model)

• Other industrial Ethernet protocols

• Power Supply:

• Typically supplied by the Freelance system bus

• Power Consumption:

• Refer to the datasheet of the specific model

• Ambient Temperature:

• Operating Temperature Range: Typically -25 °C to +70 °C (refer to the datasheet of the specific model)

• Storage Temperature Range: Typically -40 °C to +85 °C (refer to the datasheet of the specific model)

• Protection Class:

• Typically IP20

• Dimensions (W x H x D):

• Refer to the datasheet of the specific model

• Weight:

• Refer to the datasheet of the specific model

• Mounting:

• DIN rail mounting

Product Advantages

• Dual-Channel Flexibility:

• Two independent Ethernet interfaces provide flexible network connection options, such as connecting to different networks or implementing network redundancy.

• Wide Compatibility:

• Supports various common Ethernet protocols, facilitating integration with a wide range of supervisory systems and devices.

• High-Performance Communication:

• High-speed Ethernet interfaces ensure fast and reliable data transmission.

• System Integration:

• Seamless integration with Freelance controllers and I/O modules as part of the Freelance system.

• Industrial-Grade Reliability:

• Robust industrial design suitable for harsh industrial environments.

Precautions

• Correct Installation:

• Install and wire according to the installation manual for the ABB Freelance system.

• Network Configuration:

• Properly configure network parameters such as IP address, subnet mask, gateway, etc., to ensure the module can communicate correctly.

• Protocol Compatibility:

• Ensure that the connected supervisory system or device supports the Ethernet protocols used by the DP820.

• Power Requirements:

• Ensure that the Freelance system bus provides sufficient power to the DP820 module.

• Environmental Conditions:

• Ensure that the operating environment temperature is within the permissible range for the module.

• Redundancy Configuration:

• If Ethernet redundancy is required, configure it according to the relevant ABB documentation.

Product Applications

• ABB Freelance DCS Systems:

• Connecting the Freelance control system to the plant Ethernet network.

• Enabling data exchange between supervisory control and data acquisition (SCADA/HMI) systems and the Freelance system.

• Used by engineering tools for remote programming and diagnostics of the Freelance system.

• Connecting to other control systems or network devices for data integration.

• Enabling Ethernet-based remote maintenance and access.
