Products Name: Schneider 170ADO35000 Input Module
PRODUCT DESCRIPTION
Schneider Modicon Momentum 170ADO35000 Overview
The Schneider Electric Modicon Momentum 170ADO35000 is an analog output module for the Modicon Momentum Programmable Logic Controller (PLC) system. It provides 8 independent analog output channels that convert digital data from the PLC into analog signals (typically voltage or current) required for industrial control applications.
Product Detailed Description
Function:
Converts digital output data from the PLC into analog voltage or current signals.
Provides 8 independent analog output channels.
Each channel can be configured to output either a voltage or current signal.
Used to control various analog actuators such as valves, drives, regulators, etc.
Features:
8 independent analog output channels.
Each channel configurable for voltage (0-10V, +/-10V) or current (0-20mA, 4-20mA) output.
High resolution for precise analog output signals.
Opto-isolation for enhanced immunity to electrical noise.
Removable terminal blocks for easy wiring and maintenance.
LED indicators for diagnosing module and channel status.
Compatible with Modicon Momentum PLC systems.
Product Parameters
Number of Analog Output Channels: 8
Output Type (per channel configurable):
Voltage: 0-10V, +/-10V
Current: 0-20mA, 4-20mA
Resolution: 12 bits
Accuracy:
Voltage Output: +/- 0.1% FSR (Full Scale Range)
Current Output: +/- 0.1% FSR (Full Scale Range)
Update Rate: Typically 1 ms per channel
Output Load Capability:
Voltage Output: Minimum load 1 kΩ
Current Output: Maximum load 500 Ω
Isolation: Opto-isolation
Power Supply: 24 V DC (supplied via backplane)
Current Consumption: Typically 100 mA
Wiring: Removable screw terminals
LED Indicators:
Module Status (RUN, ERR)
Channel Status (Output Active)
Operating Temperature: -25 °C to +70 °C (-13 °F to 158 °F)
Storage Temperature: -40 °C to +85 °C (-40 °F to 185 °F)
Dimensions: (Refer to Schneider Electric official manual for specific dimensions)
Weight: (Refer to Schneider Electric official manual for specific weight)
Standards Compliance: CE, UL, cUL, CSA (Refer to Schneider Electric official manual for specific certifications)
Product Advantages
High Channel Density: 8 independent analog output channels in a single module saves system cost and space.
Flexible Output Configuration: Each channel can be independently configured for voltage or current output, meeting diverse application needs.
High Accuracy and Resolution: 12-bit resolution and high accuracy ensure precise analog signal output for accurate control.
Enhanced Reliability: Opto-isolation provides electrical noise suppression, improving system reliability and stability.
Easy Installation and Maintenance: Removable terminal blocks and LED indicators simplify wiring, installation, and troubleshooting.
Integration with Momentum System: Designed for seamless integration with Modicon Momentum PLC systems.
Precautions
Correct Wiring: Follow the wiring diagrams carefully to ensure correct connections for power, inputs, and outputs. Incorrect wiring can damage the module or cause system malfunction.
Power Requirements: Ensure the 24 V DC power supply provided to the Momentum PLC system is stable, reliable, and meets the module's power requirements.
Load Limitations: Ensure that the loads connected to the analog output channels are within their allowed ranges (minimum load for voltage output, maximum load for current output). Exceeding load limits can affect output accuracy or damage the module.
Environmental Conditions: Ensure the module operates within the specified operating temperature and humidity ranges. Avoid use in environments with excessive corrosive gases or dust.
ESD Protection: Take appropriate Electrostatic Discharge (ESD) precautions when handling and installing the module to prevent damage to sensitive electronic components.
Module Configuration: Use appropriate programming software to configure the output type (voltage or current) and range for each channel.
Regular Inspection: Periodically inspect the module's connections and status indicators to ensure proper operation.
Product Applications
Industrial Automation:
Controlling valve position in process control systems.
Controlling the speed or frequency of Variable Frequency Drives (VFDs) to control motor speed.
Controlling proportional and servo valves.
Outputting analog signals in data acquisition and monitoring systems.
Controlling heating and cooling elements.
Process Control:
Flow, pressure, and temperature control in industries such as chemical, oil & gas, and water treatment.
Motion Control:
Controlling the position and speed of actuators.
Building Automation:
Controlling dampers and valves in HVAC systems.
Controlling the brightness of lighting systems.
Test and Measurement Equipment:
Outputting programmable analog signals for testing and calibration purposes.
