ABB RF615 Feeder protection measurement and control device

ABB RF615 Overview

The ABB RF615 is a feeder protection and control recloser unit belonging to ABB’s Relion® 615 series. It is designed for the protection, control, and monitoring of distribution networks. This IED (Intelligent Electronic Device) is suitable for various feeder applications, including overhead lines and cable feeders.

Product Detailed Description

• Function:

• Provides comprehensive feeder protection, including overcurrent, earth fault, directional overcurrent, voltage, and frequency protection.

• Integrates control functions for circuit breaker control and disconnector control.

• Supports automatic reclosing functions to enhance power supply reliability.

• Offers event recording, fault recording, and monitoring functions for fault analysis and network management.

• Supports multiple communication protocols such as IEC 61850, IEC 60870-5-103, Modbus, and DNP3 for easy integration into automation systems.

• Features:

• Compact design for easy installation and commissioning.

• User-friendly HMI (Human-Machine Interface) for local operation and monitoring.

• Configurable logic functions to adapt to specific application requirements.

• Cyber security features to protect the device and system against network threats.

• Supports multiple languages.

• Seamless communication and interoperability with other devices through IEC 61850.

Product Parameters

As the ABB RF615 has various configurations and options, the following are some general parameters. Always refer to the official datasheet for the specific model:

• Rated Voltage:

• Suitable for various distribution voltage levels.

• Rated Current:

• Suitable for different feeder rated currents.

• Protection Functions:

• Overcurrent protection (50/51).

• Earth fault protection (50N/51N, 67N).

• Directional overcurrent protection (67).

• Overvoltage and undervoltage protection (59/27).

• Overfrequency and underfrequency protection (81O/81U).

• Unbalance protection (46).

• Thermal overload protection (49).

• Other protection functions (depending on the configuration).

• Control Functions:

• Circuit breaker control.

• Disconnector control.

• Automatic reclosing (79).

• Communication Interfaces:

• Ethernet (IEC 61850, IEC 60870-5-104, Modbus TCP/IP, DNP3 TCP/IP).

• RS-485 (IEC 60870-5-103, Modbus RTU, DNP3 Serial).

• Fiber optic interface (optional).

• Auxiliary Power Supply:

• AC and DC power supply options.

• Degree of Protection:

• IP enclosure rating (depending on the installation environment).

• Ambient Temperature:

• Operating temperature range (depending on the model).

Product Advantages

• Comprehensive Feeder Protection:

• Provides a wide range of protection functions to ensure reliable operation and rapid fault clearance of feeders.

• Integrated Control and Automation:

• Integrates protection, control, and automation functions into a single device, reducing system complexity and cost.

• Enhanced Power Supply Reliability:

• Automatic reclosing function helps to quickly restore power supply and reduce outage time.

• Improved Network Management:

• Event and fault recording functions facilitate fault analysis and network diagnostics.

• Strong Interoperability:

• Supports multiple communication protocols for easy integration into existing and future automation systems.

• User-Friendly:

• Intuitive HMI and configuration tools simplify operation and maintenance.

• Cyber Security:

• Built-in cyber security features protect the system from unauthorized access.

Precautions

• Correct Selection:

• Choose the appropriate RF615 model and configuration based on the specific feeder characteristics, protection requirements, and communication needs.

• Correct Installation:

• Follow ABB's installation guidelines, ensuring the device is installed in a suitable environment with correct wiring and grounding.

• Parameter Setting:

• Correctly set the parameters of protection and control functions based on the power system parameters and protection strategy.

• Communication Configuration:

• Configure communication parameters and protocols correctly according to the requirements of the automation system.

• Regular Maintenance and Testing:

• Regularly maintain and test the RF615 to ensure its proper operation and the effectiveness of protection functions.

• Cyber Security Management:

• Implement appropriate cyber security measures, such as password management, access control, and security patch updates, to protect the device and system.

Product Applications

The ABB RF615 is suitable for various feeder protection and control applications in distribution networks, including:

• Protection and control of overhead line feeders.

• Protection and control of cable feeders.

• Feeder protection units in substation automation systems.

• Industrial and commercial distribution systems.

• Protection of renewable energy grid connection feeders.
