Brand： Allen Bradley
Model number：22A-A8P0N114
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：1.453kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Description:
Cable lengths of 32 m (105 ft) for plastic cable and 200 m (656.7 ft) for
glass cable are possible for each transmission section (point A to B).
In Figure 3.24, the second Ultra3000-SE system is located in a separate
cabinet and connected with bulkhead adapters.
Figure 3.24
Fiber-Optic Ring Connection (Example 4)
To connect the SERCOS fiber-optic cables:
1. Insert one end of a fiber-optic cable into the Receive SERCOS
connector on the Ultra3000-SE and thread the connector on finger
tight.
2. Insert the other end of the cable (from step 1) into the Transmit
SERCOS connector on the ControlLogix module/SoftLogix PCI
Card and thread the connector on finger tight.
3. Insert one end of another fiber-optic cable into the Transmit
SERCOS connector on the last Ultra3000-SE drive in the ring and
thread the connector on finger tight.
IMPORTANT To avoid signal loss, do not mix glass and plastic
cables when connecting to a bulkhead adapter. Use
glass-to-glass or plastic-to-plastic cable on both sides
of the adapter.
IMPORTANT Clean the fiber-optic cable connectors prior to
installation. Dust in the connectors can reduce signal
strength. For more information, refer to Fiber Optic
Cable Installation and Handling Instructions
(publication 2090-IN010x-EN-P).
This chapter provides a description of maintenance and
troubleshooting activities for the Ultra3000. This chapter includes
these sections:
• Safety Precautions
• General Troubleshooting
• Troubleshooting for SERCOS Drives
• Troubleshooting for DeviceNet Drives
For power-up procedures and system integration with Ultraware or
ControlLogix and SoftLogix modules/PCI cards (see table below) refer
to the Ultra3000 Digital Servo Drives Integration Manual (publication
2098-IN005x-EN-P). Manuals are available electronically (as a .pdf) or
in hardcopy from www.theautomationbookstore.com.
