AB 47CN4-4002 Multi-turn absolute encoder

Allen-Bradley 47CN4-4002 Overview

The Allen-Bradley 47CN4-4002 is an absolute encoder belonging to the Bulletin 847 series. Absolute encoders retain their position information even after a power loss, making them ideal for applications requiring precise position feedback.

Product Detailed Description

• Function:

• Provides absolute position information of a rotating shaft.

• Each position has a unique digital code that is maintained even after a power failure.

• Output signals are typically parallel, SSI, or other digital interfaces.

• Features:

• Rugged industrial-grade design suitable for harsh environments.

• High resolution providing precise position feedback.

• Multiple mounting and connection options.

• Absolute position information eliminates the need for homing after startup.

Product Parameters

As the model number is very specific, the following are typical parameters for the Bulletin 847 series absolute encoders. Always refer to the official datasheet for the specific 47CN4-4002 model:

• Type:

• Absolute Encoder

• Resolution:

• Varies by specific model (e.g., 10-bit, 12-bit per revolution, etc.).

• Output Code:

• Varies by specific model (e.g., Binary, Gray code).

• Interface:

• Varies by specific model (e.g., Parallel, SSI).

• Supply Voltage:

• Varies by specific model (e.g., 5 V DC, 10-30 V DC).

• Shaft Type:

• Solid shaft or hollow shaft.

• Protection Degree:

• Varies by specific model (e.g., IP65, IP67).

• Operating Temperature:

• Varies by specific model (e.g., -20 °C to +85 °C).

• Maximum Rotational Speed:

• Varies by specific model.

• Connection Type:

• Cable or connector.

Product Advantages

• Absolute Position Feedback:

• No need for re-homing after power loss, saving startup time and increasing reliability.

• High Accuracy:

• Provides precise position information, suitable for applications requiring accurate positioning.

• Robust and Durable:

• Industrial-grade design ensures reliable operation in harsh environments.

• Multiple Interface Options:

• Adapts to different control system requirements.

Precautions

• Correct Installation:

• Follow Allen-Bradley's installation guidelines, ensuring the encoder is securely mounted and correctly coupled to the drive shaft.

• Power Connection:

• Ensure the power supply voltage is within the allowable range and connect the power and signal wires correctly.

• Environmental Conditions:

• Avoid using the encoder in environments exceeding its operating temperature and humidity ranges.

• Protect against strong vibrations and shocks.

• Signal Cable Shielding:

• To reduce electromagnetic interference, it is recommended to use shielded cables for signal connections.

• Refer to Official Manual:

• Always refer to the official datasheet for the specific 47CN4-4002 model for accurate parameters and installation instructions.

Product Applications

• Industrial Automation:

• Servo motor feedback.

• Robotics.

• Material handling systems.

• Packaging machinery.

• Machine Tools:

• Positioning control.

• Tool changing systems.

• Printing Machinery:

• Registration control.

• Textile Machinery:

• Tension control.

• Medical Equipment:

• Precision positioning systems.
