AB 800H-NP15 Button unit

Brand:AB

Model number:800H-NP15

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.225kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

AB 800H-NP15 Button unit


INQUIRE NOW

Products Name: AB 800H-NP15 Button unit

PRODUCT DESCRIPTION

Allen-Bradley 800H-NP15 Push Button Overview

The Allen-Bradley 800H-NP15 is a 22.5 mm diameter metal push button belonging to the 800H series. This series of push buttons is known for its rugged durability and reliable performance in various industrial applications. The specific designation "NP15" likely indicates the button's configuration, such as the number and type of contacts, color, or operating action.

Product Detailed Description

  • Function:

    • Serves as a control element on operator interfaces for starting, stopping, or selecting functions of machines and equipment.

    • Controls circuits by closing or opening electrical contacts when the button is pressed.

  • Features:

    • 22.5 mm mounting hole diameter.

    • Metal construction provides excellent durability and impact resistance.

    • May have different contact configurations (e.g., Normally Open NO, Normally Closed NC).

    • May have different operator head types (e.g., raised, flush, shrouded).

    • Typically features an IP66 protection rating, suitable for harsh industrial environments.

    • May be available in various color options.

    • Easy to install and wire.

Product Parameters

Since the specific configuration of the Allen-Bradley 800H-NP15 will affect its parameters, the following are typical parameters for the 800H series push buttons. Always refer to the official datasheet for the specific model for accurate information:

  • Mounting Hole Diameter:

    • 22.5 mm

  • Material:

    • Metal (typically zinc alloy or stainless steel)

  • Contact Configuration:

    • May offer configurations such as 1NO, 1NC, 1NO/1NC, 2NO, 2NC.

  • Rated Operating Voltage (Ue):

    • Varies depending on the contact block, e.g., 24V AC/DC, 120V AC, 230V AC.

  • Rated Operating Current (Ie):

    • Varies depending on the contact block, e.g., 3A, 6A.

  • Degree of Protection (IP):

    • Typically IP66 (front)

  • Operating Temperature:

    • Typically -25 °C to +70 °C

  • Mechanical Life:

    • Typically 10^6 operations or more

  • Electrical Life:

    • Typically 10^5 operations or more

  • Terminal Type:

    • Screw terminals

  • Standards Compliance:

    • IEC 60947-5-1, UL 508, CSA C22.2 No. 14, etc.

Product Advantages

  • Rugged and Durable:

    • Metal construction and robust design enable it to withstand harsh industrial environments.

  • High Reliability:

    • Allen-Bradley brand is known for its high quality and reliability.

  • Wide Variety of Choices:

    • The 800H series offers various contact configurations, operator head types, and color options to meet different application needs.

  • High Protection Rating:

    • Typically features an IP66 protection rating, dustproof and waterproof.

  • Easy Installation:

    • Standard 22.5 mm mounting hole diameter and simple wiring make installation easy.

  • Global Versatility:

    • Complies with multiple international standards, suitable for the global market.

Precautions

  • Correct Selection:

    • Choose the appropriate 800H-NP15 configuration based on specific application requirements (e.g., number and type of contacts, operating action, color).

  • Correct Installation:

    • Follow Allen-Bradley's installation guidelines, ensuring the button is securely mounted and correctly wired.

  • Environmental Conditions:

    • Ensure the operating environment temperature is within the allowable range.

  • Electrical Safety:

    • Always adhere to electrical safety regulations during installation and maintenance.

  • Regular Inspection:

    • Periodically inspect the mechanical action and electrical contacts of the button to ensure proper operation.

Product Applications

  • Industrial Automation:

    • Start, stop, and emergency stop buttons on control panels.

    • Operator interface for machines and equipment.

  • Process Control:

    • Used to control valves, pumps, and other equipment.

  • Material Handling:

    • Controlling conveyors, cranes, and other equipment.

  • Packaging Machinery:

    • Used to control various stages of the packaging process.

  • Other Industrial Equipment:

    • Any equipment requiring manual operation for control.
