Product Detailed Description
Function: The primary function of the D0232 is to convert digital control signals from a PLC or controller into discrete electrical outputs to actuate or switch external devices. It acts as an interface between the control system's logic and the physical components in the field.
Output Capabilities: It features a high number of digital output channels (typically 32 outputs). These outputs are designed for 24 V DC operation. The module can provide a specific current per channel (e.g., 1 A), and some outputs can be connected in parallel for higher current requirements.
Monitoring and Protection: A key feature of the D0232 is its integrated monitoring capabilities. It can detect and report faults such as short circuits, wire breaks, and overloads on the output channels. This enhances system reliability and simplifies troubleshooting.
LED Status Indication: Each channel typically has a dedicated LED indicator that provides visual feedback on its current status (e.g., active, inactive, fault). This aids in quick diagnosis during commissioning or operation.
Compact Design: The module is designed to be space-saving, which is beneficial in control cabinets where panel space is often at a premium.
Galvanic Isolation: It provides galvanic isolation from the system, enhancing safety and protecting the control system from potential electrical disturbances in the field.
Grouping: Outputs are often divided into groups (e.g., 2 groups), which can sometimes allow for different power supplies per group, providing more flexibility in wiring and power management.
Cold Climate Version: A "DO232 CC" variant exists specifically designed for cold climate applications, indicating extended temperature range capabilities.
Product Parameters
(Note: Specific parameters can vary slightly depending on revisions or specific sub-models like DO232 CC. Always refer to the official Bachmann electronic datasheet for the precise model number you are working with.)
Number of Outputs: 32 digital outputs.
Output Voltage: 24 V DC (nominal).
Output Current per Channel: Typically 1 A (for 32 outputs) or 2.5 A (for 16 outputs in some variants like DIO232, but DO232 is typically 32x 1A).
Total Current per Group: Max. 8 A (for output groups).
Number of Groups: 2 groups (e.g., 1-16 and 17-32).
Switching Delay (Resistive Load):
Galvanic Isolation from the System: 500 V.
Monitoring Features: Short-circuit, wire break, and overload monitoring.
Status Indication: LED per channel.
Power Supply (Internal Logic): Provided by the backplane/controller.
Operating Temperature:
Relative Humidity (Operation): 5 % to 95 % (non-condensing or with condensation depending on model/environment).
Storage Temperature: -40 °C to +85 °C.
Mounting: DIN rail mountable (part of the Bachmann M200 system).
Dimensions: Compact module design.
Connection: Likely screw terminals for wiring.
Product Advantages
High Channel Density: Provides 32 outputs in a compact form factor, saving cabinet space and wiring complexity.
Enhanced Reliability: Integrated monitoring for short-circuit, wire break, and overload ensures quick detection of faults and helps prevent damage to connected devices or the module itself.
Diagnostic Capabilities: Per-channel LED status indicators and fault reporting facilitate rapid troubleshooting and minimize downtime.
Flexibility in Powering: Output grouping potentially allows for different power supplies, enabling separation of loads or redundancy.
Robustness: Designed for industrial environments, ensuring stable operation in demanding conditions.
Galvanic Isolation: Provides crucial electrical separation, enhancing system safety and preventing ground loops or voltage surges from affecting the controller.
Optimized for Bachmann Systems: Seamless integration with Bachmann M200 controllers and other modules.
Precautions
Correct Wiring: Strictly adhere to the wiring diagrams provided in the Bachmann manual. Incorrect wiring can damage the module or connected devices. Pay attention to correct polarity for DC outputs.
Load Current: Do not exceed the maximum permissible current per channel or the total current per group/module. Parallel connection of outputs for higher current must be done according to manufacturer guidelines.
Power Supply: Ensure a stable and correctly rated 24 V DC power supply is provided for the outputs, as well as for the controller powering the module's logic. Use fuses as recommended.
Environmental Conditions: Operate the module within its specified temperature and humidity ranges. If operating in cold or harsh environments, ensure the "CC" (Cold Climate) version is used.
Safety Standards: Installation and commissioning should be performed by qualified personnel in accordance with all relevant local and national electrical safety codes and industrial automation standards.
ESD Protection: Take electrostatic discharge (ESD) precautions when handling the module to prevent damage to sensitive electronic components.
Firmware Compatibility: Ensure the firmware version of the Bachmann controller is compatible with the D0232 module.
Cable Routing: Route power, signal, and communication cables separately where possible to minimize electromagnetic interference (EMI).
Product Applications
The Bachmann D0232 Digital Output Module is ideal for a wide array of industrial automation and control applications where precise and reliable switching of digital loads is required.
