Detailed Product Description
The Bently Nevada 990-05-50-01-00 is a 2-wire vibration transmitter designed primarily for original equipment manufacturers (OEMs) of centrifugal air compressors, small pumps, motors, or fans. It offers a
simple and reliable solution for providing a proportional vibration signal to a machinery control system.
Key Features and Specifications
Model: 990 - Vibration Transmitter
Full-scale Option: -05 - 0-5 mils pp (0-125 µm pp)
Signal Output: 4 to 20 mAdc over specified full-scale range in 2-wire configuration
Frequency Response: 5 Hz to 6,000 Hz +0, -3 dB
Operating Temperature: -35°C to +85°C
Power: Requires +12 to +35 Vdc input at the transmitter terminal
Transducer case material: AISI 303 or 304 Stainless Steel (SST)
Weight: 0.43kg
Warranty: 12 Months
Product Advantages
Simplicity: Provides a straightforward 4 to 20 mA output for easy integration into control systems.
Reliability: Constructed with high-quality materials and designed for harsh industrial environments.
Accuracy: Offers precise vibration measurement for effective condition monitoring.
Flexibility: Can be customized with various options to meet specific application requirements.
Precautions
Installation: Follow the manufacturer's guidelines for proper installation to ensure accurate measurements.
Calibration: Regular calibration is recommended to maintain accuracy over time.
Environmental Conditions: Avoid exposing the transmitter to excessive vibration, shock, or corrosive environments.
Power Supply: Ensure a stable power supply to prevent measurement errors.
Applications
Additional Information
Datasheet: A comprehensive datasheet is available on the Baker Hughes website for detailed technical specifications.
OEM Focus: This product is primarily targeted at original equipment manufacturers.
Customization: Various options are available to customize the transmitter for specific applications.
Note: The information provided here is based on publicly available data and may not be entirely comprehensive. It is recommended to consult the manufacturer's datasheet and contact a sales representative for the
most accurate and up-to-date information.
