GE IC200MDD848 Controller digital input/output modules

GE IC200MDD848 Overview

The GE IC200MDD848 is a VersaMax Micro Controller Digital Input/Output Module. It provides digital input and output channels for the GE VersaMax Micro PLC system.

Product Detailed Description

• Function:

• Provides 32 digital input channels and 32 digital output channels.

• Input channels are used to receive discrete signals from field devices (e.g., sensors, switches).

• Output channels are used to control field devices (e.g., relays, indicators, small motors).

• Outputs are sinking type.

• Features:

• High-density I/O, providing a large number of input and output points in a single module.

• 24 VDC input voltage.

• 24 VDC sinking output voltage.

• Pluggable terminal blocks for easy wiring and maintenance.

• Compatible with the GE VersaMax Micro PLC system.

Product Parameters

• Number of Input Points: 32 points

• Input Voltage: 24 VDC (12-24 VDC)

• Input Type: Sinking or Sourcing, depending on wiring

• Input Current: 7 mA @ 24 VDC (typical)

• Number of Output Points: 32 points

• Output Voltage: 24 VDC (5-30 VDC)

• Output Type: Sinking

• Output Current: 0.5 A max per point, 4 A max per group (16 points)

• Isolation: Optical isolation

• Response Time (On/Off): 10 ms max

• Wiring Method: Pluggable screw terminals

• Operating Temperature: -40 °C to +70 °C (-40 °F to +158 °F)

• Storage Temperature: -40 °C to +85 °C (-40 °F to +185 °F)

• Humidity: 5% to 95% non-condensing

• Dimensions: ¹ Refer to the official GE manual for specific dimensions

• Weight: Refer to the official GE manual for specific weight

• Compatible PLC Series: GE VersaMax Micro

Product Advantages

• High-Density I/O: Provides a large number of I/O points in a single module, saving space and cost.

• Flexibility: Inputs can be configured as sinking or sourcing depending on the wiring.

• Easy Wiring and Maintenance: Pluggable terminal blocks simplify installation and replacement.

• Reliability: Industrial-grade design for reliable operation in harsh environments.

• Integration with VersaMax Micro System: Seamless integration into the GE VersaMax Micro PLC system.

Precautions

• Correct Wiring: Ensure proper wiring according to GE's wiring diagrams to avoid damage to the module and connected devices.

• Voltage and Current Limits: Do not exceed the module's rated voltage and current limits.

• Environmental Conditions: Use the module within its specified operating temperature and humidity ranges.

• Electrostatic Discharge (ESD) Protection: Take appropriate ESD precautions when handling the module.

• Power Supply Isolation: Ensure proper isolation of input and output power supplies.

• Fuse Protection: It is recommended to install appropriate fuses in external circuits to protect the module and field devices.

Product Applications

• Industrial Automation: Used for signal acquisition and control in various automation systems.

• Machine Control: Controlling actuators, sensors, and indicators of machinery.

• Process Control: Monitoring and controlling discrete signals in industrial processes.

• Packaging Machinery: Controlling sensors and actuators in packaging equipment.

• Material Handling: Controlling conveyors, sorting systems, etc.
