NI PX1-6115 DAQ Module

Brand: National Instruments

Model number:PX1-6115

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.19kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

NI PX1-6115 DAQ Module


INQUIRE NOW

Products Name: NI PX1-6115 DAQ Module

PRODUCT DESCRIPTION

NI PXIe-6115 Overview

The NI PXIe-6115 is a high-performance PXI Express data acquisition (DAQ) module. It offers simultaneous sampling analog input channels with high sampling rates and resolution, suitable for a variety of applications requiring precise and high-speed data acquisition.

Product Detailed Description

  • Function:

    • Simultaneously acquires data from multiple analog input channels.

    • Provides high sampling rates to capture rapidly changing signals.

    • Offers high resolution for precise measurements.

    • Onboard signal conditioning simplifies system design.

    • Seamless integration with NI-DAQmx driver software for easy programming and configuration.

    • High-speed data transfer via the PXI Express bus.

  • Features:

    • 4 simultaneously sampled analog input channels.

    • Up to 2.5 MS/s sampling rate per channel.

    • 14-bit resolution.

    • ±10 V analog input range.

    • 5 MHz analog input bandwidth.

    • Onboard memory of 64 MS per channel for onboard data buffering.

    • PXI Express x1 interface.

    • Supports external clock and triggering.

Product Parameters

  • Number of Analog Input Channels: 4 Simultaneous Sampling

  • Sampling Rate (per channel): Up to 2.5 MS/s

  • Resolution: 14-bit

  • Analog Input Range: ±10 V

  • Analog Input Coupling: DC

  • Input Impedance: 1 MΩ parallel with 100 pF

  • Analog Input Bandwidth (-3 dB): 5 MHz

  • Overvoltage Protection: ±30 V

  • Onboard Memory (per channel): 64 MS

  • External Clock Input: Supported

  • External Trigger: Digital Trigger Input

  • Bus Interface: PXI Express x1

  • Power Supply Voltage: +3.3 V, +12 V

  • Power Consumption: 14.1 W typical, 17.7 W maximum

  • Operating Temperature: 0 °C to 55 °C

  • Storage Temperature: -20 °C to 70 °C

  • Relative Humidity: 10% to 90% RH, noncondensing

  • Size: 3U PXIe Module

  • Weight: 250 g

Product Advantages

  • High-Performance Data Acquisition:

    • High sampling rate and high resolution suitable for precise measurement of rapidly changing signals.

  • Simultaneous Sampling:

    • Multiple channels acquire data synchronously, ensuring time consistency between channels.

  • Easy Integration and Programming:

    • Seamless integration with NI-DAQmx driver software, providing rich APIs and tools.

    • Compatible with various programming languages such as LabVIEW, Python, C/C++.

  • High-Speed Data Transfer:

    • PXI Express bus provides high bandwidth, ensuring fast data transfer.

  • Onboard Memory:

    • Large onboard memory allows for long-duration data acquisition without host intervention.

  • Flexible Clocking and Triggering:

    • Supports external clock and triggering for easy synchronization with other instruments.

Precautions

  • Correct Installation:

    • Install the PXIe-6115 module correctly into a compatible PXI Express chassis.

  • Power Requirements:

    • Ensure the PXI Express chassis provides sufficient power.

  • Signal Connections:

    • Use appropriate cables and terminal blocks to connect analog input signals.

  • Software Installation:

    • Install the NI-DAQmx driver software on the host computer.

  • Electrostatic Discharge (ESD) Protection:

    • Observe ESD precautions when handling the module.

  • Environmental Conditions:

    • Ensure the operating environment temperature and humidity are within the specified range.

  • Calibration:

    • For guaranteed measurement accuracy, regular calibration of the module is recommended.

Product Applications

  • Transient Recording:

    • Capturing fast transient signals.

  • Ultrasonic Testing:

    • High-speed acquisition of signals from ultrasonic sensors.

  • Vibration Analysis:

    • Simultaneous acquisition of signals from multiple vibration sensors.

  • Shock and Impact Testing:

    • High-speed acquisition of data from shock and impact events.

  • Acoustic Emission Testing:

    • Acquiring acoustic wave signals emitted during material fracture or deformation.

  • Power Quality Analysis:

    • Simultaneous measurement of voltage and current waveforms.

  • Control System Prototyping:

    • High-speed data acquisition for real-time control algorithm development.
