Honeywell CC-IP0101 Redundant Ethernet interface module

Honeywell CC-IP0101 Overview

The Honeywell CC-IP0101 is a redundant Ethernet interface module typically used in Honeywell Experion LX and Experion PKS control systems. It provides a high-speed and reliable communication interface between the control network and external Ethernet networks.

Product Detailed Description

• Function:

• Provides data exchange between the Honeywell control network (e.g., ControlNet, Ethernet Control Network) and external Ethernet networks (e.g., enterprise networks, third-party systems).

• Supports various communication protocols such as TCP/IP, UDP, Modbus TCP, etc.

• Offers redundancy functionality to ensure that the system can automatically switch to a backup path in case of a failure in the primary communication path, thereby improving system availability.

• Typically has an onboard processor and memory for handling communication tasks.

• Supports network diagnostic functions, making it easy for users to monitor network status and troubleshoot problems.

• Features:

• Redundant Ethernet interface for enhanced system reliability.

• High-speed data transmission to meet real-time control requirements.

• Supports multiple industrial communication protocols for easy integration.

• Rugged industrial design suitable for harsh environments.

• Easy to configure and maintain.

Product Parameters

As there may be different versions or configurations of the CC-IP0101, the following are typical parameters for redundant Ethernet interface modules. Always refer to the official datasheet for the specific CC-IP0101 model:

• Interface Type:

• 10/100/1000Base-T Ethernet interface (typically two or more ports for redundancy).

• Supported Protocols:

• TCP/IP, UDP, HTTP, SNMP, Modbus TCP, etc.

• Data Transfer Rate:

• Up to 1 Gbps.

• Power Requirements:

• Typically 24 V DC.

• Power Consumption:

• Varies depending on the specific model.

• Operating Temperature:

• Typically -40 °C to +70 °C (varies by specific model).

• Storage Temperature:

• Typically -40 °C to +85 °C (varies by specific model).

• Humidity:

• 5% to 95% non-condensing.

• Protection Degree:

• Typically meets industrial standards.

• Dimensions and Weight:

• Varies depending on the specific model.

• Certifications:

• CE, UL, etc. (refer to the specific product manual).

Product Advantages

• High Reliability:

• Redundant design ensures continuous availability of the communication link, improving the overall reliability of the control system.

• High-Speed Communication:

• Gigabit Ethernet interface provides high-speed data transmission, meeting the needs of real-time control and large data exchange.

• Wide Compatibility:

• Supports multiple industrial standards and common communication protocols, facilitating integration with various third-party systems.

• Robust and Durable:

• Industrial-grade design that can operate stably in harsh industrial environments.

• Easy Integration:

• Specifically designed for Honeywell Experion systems, making integration convenient.

• Enhanced Network Management:

• Supports network management protocols such as SNMP for easy remote monitoring and management.

Precautions

• Correct Installation:

• Follow Honeywell's installation guidelines, ensuring the module is correctly installed in the cabinet and connected to the appropriate networks.

• Power Requirements:

• Use a power supply that meets the specifications and ensure reliable power connections.

• Network Configuration:

• Correctly configure network parameters such as IP address, subnet mask, gateway, etc., to ensure the module can communicate normally with other devices.

• Redundancy Configuration:

• If using redundancy, correctly configure the primary and backup network interfaces and related redundancy protocols.

• Environmental Conditions:

• Ensure that the operating environment temperature, humidity, etc., are within the module's allowable range.

• Firmware Upgrade:

• Regularly check and upgrade the module's firmware as needed to obtain the latest features and security patches.

• Security Protection:

• Take necessary network security measures to protect the control network from unauthorized access.

Product Applications

• Honeywell Experion Control Systems:

• Connecting control networks and enterprise networks.

• Integrating third-party systems (e.g., MES, historical databases).

• Enabling remote monitoring and diagnostics.

• Connecting operator stations and engineering stations.

• Building distributed control systems.

• Other Industrial Automation Systems:

• Applied in scenarios requiring redundant Ethernet communication interfaces.
