NI SBRIO-9607 Overview
The NI SBRIO-9607 is a high-performance, rugged, real-time controller that integrates an FPGA, a real-time processor, and analog/digital I/O modules. It is part of the NI Single-Board RIO series and is designed for embedded control and data acquisition applications that require high performance, reliability, and flexibility.
Product Detailed Description
Function:
Real-time control and monitoring of industrial systems and equipment.
High-speed data acquisition and processing.
FPGA implementation for custom hardware acceleration and control algorithms.
Communication and networking via various interfaces.
Rugged design for harsh industrial environments.
Features:
1 x 10/100 Ethernet port.
1 x RS-232 serial port.
1 x CAN port.
1 x USB 2.0 Host port.
Real-Time Processor: Freescale PowerPC 400 MHz processor for reliable real-time operation.
FPGA: Xilinx Spartan-3 FPGA for custom hardware logic and acceleration.
Analog Input (AI): 8 analog input channels, 16-bit resolution, up to 200 kS/s sampling rate.
Analog Output (AO): 4 analog output channels, 16-bit resolution, up to 250 kS/s update rate.
Digital Input/Output (DIO): 40 digital input/output channels, configurable as input or output.
Communication Interfaces:
Memory: 256 MB DRAM, 256 MB nonvolatile memory.
Programming Environment: NI LabVIEW Real-Time and LabVIEW FPGA Modules.
Product Parameters
Processor: Freescale PowerPC 400 MHz
FPGA: Xilinx Spartan-3
Analog Input: 8 channels, 16-bit, 200 kS/s
Analog Output: 4 channels, 16-bit, 250 kS/s
Digital I/O: 40 channels (configurable as input or output)
Ethernet: 1 x 10/100Base-T
Serial: 1 x RS-232
CAN: 1 x
USB: 1 x USB 2.0 Host
Memory: 256 MB DRAM, 256 MB nonvolatile memory
Operating Temperature: -40 °C to 70 °C
Shock and Vibration: Meets industrial standards
Dimensions: 152.4 mm x 127 mm
Power: 9 VDC to 30 VDC
Product Advantages
High Performance: Combination of real-time processor and FPGA provides powerful computing and flexible hardware acceleration.
Rugged and Reliable: Wide operating temperature range and high shock and vibration resistance for harsh environments.
Flexibility: FPGA can be used to implement custom hardware logic and control algorithms.
Integrated: Integrates real-time processor, FPGA, and analog/digital I/O on a single board, saving space and cost.
Easy Programming: Graphical programming using NI LabVIEW Real-Time and LabVIEW FPGA Modules.
Rich Communication Interfaces: Supports various industrial communication protocols.
Precautions
Power Supply: Ensure the use of a power supply that meets the specifications.
Temperature: Operate within the specified operating temperature range and ensure proper heat dissipation.
Electrostatic Discharge (ESD): Take anti-static precautions when handling the board.
Software Compatibility: Ensure the version of NI LabVIEW software used is compatible with the hardware.
Wiring: Carefully follow the wiring diagrams to connect signal lines, avoiding short circuits and open circuits.
FPGA Programming: FPGA programming requires specialized LabVIEW FPGA development skills.
Product Applications
Industrial Control: Machine control, motion control, process control.
Data Acquisition and Monitoring: High-speed data acquisition, condition monitoring, fault diagnosis.
Embedded Systems: Autonomous robots, smart sensors, customized embedded controllers.
Aerospace and Defense: Flight control, radar systems, signal processing.
Automotive Testing: ECU testing, sensor calibration, durability testing.
Research: Rapid prototyping, custom instrumentation.
