05-0003-000800BN Bartec Output module

Bartec Modules Overview

Bartec is a leading global provider of explosion-proof electrical equipment and solutions. Their modular product range is extensive and designed for various industrial applications in potentially explosive atmospheres. These modules typically include components for automation, control, connectivity, and sensing.

Product Detailed Description

As Bartec offers a diverse range of modular products, the following provides general information and covers some common types of Bartec modules:

• Explosion-Proof I/O Modules:

• Used for the safe connection and control of sensors, actuators, and other field devices in hazardous areas.

• Available in intrinsically safe (IS) and non-intrinsically safe options.

• Include analog inputs/outputs, digital inputs/outputs, and special function modules.

• Explosion-Proof Control Modules:

• Used for implementing local control functions in hazardous areas.

• May include pushbuttons, switches, indicators, and displays.

• Explosion-Proof Connection Modules:

• Used for the safe connection of cables and equipment in hazardous areas.

• Offer various connectors, junction boxes, and cable assemblies.

• Explosion-Proof Communication Modules:

• Used for enabling safe data communication in hazardous areas.

• Support various industrial protocols such as Modbus, PROFIBUS, and Ethernet.

• Explosion-Proof Power Supply Modules:

• Used for providing safe power to equipment in hazardous areas.

• Offer intrinsically safe and non-intrinsically safe power solutions.

Product Parameters

Due to the wide variety of Bartec modules, parameters will vary depending on the specific model. The following are some potential parameters to consider. Always refer to the official datasheet for the specific model:

• Explosion Protection Rating:

• Ex ia IIC T4 Gb, Ex ib IIC T4 Gb, Ex d IIC T6 Gb, etc. (depending on the specific model and area requirements).

• Number of Input/Output Channels:

• E.g., 8 DI, 4 DO, 4 AI, 2 AO (depending on the specific model).

• Signal Types:

• E.g., 4-20 mA, HART, 24V DC, 110V AC (depending on the specific model).

• Supply Voltage:

• E.g., 24V DC, 110/230V AC (depending on the specific model).

• Operating Temperature Range:

• E.g., -40 °C to +70 °C (depending on the specific model).

• Protection Degree:

• E.g., IP65, IP66 (depending on the specific model).

• Communication Protocols:

• E.g., Modbus RTU, PROFIBUS DP, Ethernet (depending on the specific model).

• Connection Methods:

• E.g., screw terminals, spring terminals, specific connector types (depending on the specific model).

• Dimensions and Weight:

• Varies by model.

• Certifications:

• ATEX, IECEx, UL, CSA, etc. (depending on the specific model and target market).

Product Advantages

• Intrinsically Safe (IS) Options:

• Suitable for the highest risk hazardous areas, reducing the risk of igniting explosive mixtures.

• Robust and Durable Design:

• Able to withstand harsh industrial environments, including extreme temperatures, humidity, and vibration.

• Modular Design:

• Allows for flexible system configuration and expansion, easy maintenance and replacement.

• Wide Product Range:

• Provides comprehensive solutions covering automation, control, connectivity, and communication needs.

• Global Certifications:

• Complies with major international explosion protection standards and certifications.

• High Reliability:

• Designed to provide dependable performance in critical and hazardous applications.

• Easy Integration:

• Designed for seamless integration with various control systems and field devices.

Precautions

• Correct Selection:

• Choose the appropriate Bartec module based on the specific hazardous area classification, application requirements, signal types, and environmental conditions.

• Adhere to Explosion Protection Regulations:

• Installation, wiring, and operation must be carried out in accordance with applicable explosion protection standards and local regulations.

• Qualified Personnel:

• Installation and maintenance should be performed by trained and qualified personnel.

• Regular Inspection and Maintenance:

• Regularly inspect the physical condition, connections, and functionality of the modules to ensure proper operation and explosion protection integrity.

• Use Correct Cables and Accessories:

• Ensure that the correct explosion-proof cables, glands, and accessories are used.

• Avoid Modifications:

• Any unauthorized modifications to explosion-proof modules are strictly prohibited.

• Environmental Conditions:

• Ensure the operating environment is within the module's permissible temperature, humidity, and vibration limits.

Product Applications

Bartec modules are widely used in various industrial sectors with potentially explosive atmospheres, including but not limited to:

• Oil and Gas:

• Drilling platforms, refineries, petrochemical plants, pipelines.

• Chemical and Pharmaceutical:

• Production plants, storage facilities.

• Food and Beverage:

• Alcohol production, sugar refineries, flour mills.

• Paint and Coatings:

• Production and spraying facilities.

• Wastewater Treatment:

• Biogas areas.

• Mining:

• Underground and surface operations.

• Marine and Offshore:

• Tankers, FPSOs.
