AMCI 1541-03 Single-turn absolute encoder module

AMCI 1541-03 Overview

The AMCI (Advanced Micro Controls Inc.) 1541-03 is a single-turn absolute encoder module designed to interface with various industrial control systems, providing precise position feedback. It is typically used in applications requiring accurate angular or linear position measurement.

Product Detailed Description

• Function:

• Provides single-turn (360 degrees) absolute position information.

• Outputs parallel binary or Gray code data, depending on the configuration.

• Designed for direct connection to digital inputs of PLCs or other controllers.

• Offers high-resolution position measurement.

• Rugged industrial-grade design for harsh environments.

• Features:

• Single-turn absolute encoder.

• Parallel output (binary or Gray code, user-configurable).

• High resolution (depending on the model).

• Rugged industrial packaging.

• Multiple mounting options.

Product Parameters

As the AMCI 1541 series has different configurations, the following are some general parameters. Always refer to the official datasheet for the specific AMCI 1541-03 model:

• Encoder Type:

• Single-turn absolute.

• Output Code:

• Parallel binary or Gray code (user-selectable).

• Resolution:

• Typically 10-bit or 12-bit (1024 or 4096 counts per revolution), depending on the model.

• Supply Voltage:

• Typically 5 V DC or 24 V DC.

• Output Signal Level:

• Compatible with the supply voltage (e.g., TTL or 24 V DC).

• Interface:

• Parallel data output lines.

• Power and ground lines.

• Protection Degree:

• Typically IP65 or higher.

• Operating Temperature:

• Typically -25 °C to +85 °C.

• Mechanical Characteristics:

• Shaft diameter and mounting style vary by model.

Product Advantages

• Absolute Position Feedback:

• Provides accurate position information immediately after power-up, without the need for homing.

• High Accuracy:

• Offers high-resolution position measurement.

• High Reliability:

• Rugged industrial design for harsh environments.

• Easy Integration:

• Parallel output is easy to interface with various PLCs and controllers.

• User-Configurable Output Code:

• Binary or Gray code output can be selected to suit different controller input requirements.

Precautions

• Correct Installation:

• Follow AMCI's installation guidelines, ensuring the encoder is securely mounted and the shaft is correctly aligned.

• Power Connection:

• Ensure the power supply voltage matches the encoder requirements and connect the power and ground lines correctly.

• Signal Line Connection:

• Connect the parallel data output lines correctly to the digital input terminals of the controller.

• Environmental Conditions:

• Avoid using the encoder in environments exceeding its operating temperature and humidity ranges.

• Protect the encoder from strong shocks and vibrations.

• EMC Compatibility:

• Consider electromagnetic compatibility during wiring to avoid electromagnetic interference affecting encoder performance.

Product Applications

• Industrial Automation:

• Precise position control.

• Servo motor feedback.

• Robotics.

• Packaging Machinery:

• Positioning and synchronization control.

• Printing Machinery:

• Precise registration control.

• Metalworking Machinery:

• Positioning and feed control.

• Material Handling:

• Position feedback for stacker cranes and conveyor systems.
