AutomationDirect E-SW05U Ethernet Switch

AutomationDirect E-SW05U Unmanaged Industrial Ethernet Switch Overview

The AutomationDirect E-SW05U is a compact, unmanaged industrial Ethernet switch from their "ETHERNET" series. It is designed to provide reliable network connectivity in demanding industrial environments. Being unmanaged, it offers simple plug-and-play functionality without requiring any configuration, making it ideal for quick and easy expansion of industrial networks.

Product Detailed Description

• Functionality: The E-SW05U serves as a central connection point for Ethernet-enabled devices within an industrial network. It automatically detects and negotiates connection speeds (10/100 Mbps) and duplex modes for connected devices. As an unmanaged switch, it operates transparently, simply forwarding data packets between ports based on MAC addresses, without any advanced network management features like VLANs, QoS, or SNMP.

• Industrial Design: It's built for industrial use, featuring a robust, slim-line IP30 rated metal housing that is DIN rail mountable. This makes it suitable for installation in control cabinets and other industrial enclosures where space might be limited.

• Power Supply: The unit supports a wide range of DC power inputs, enhancing its versatility for various industrial power systems. It typically includes redundant power inputs for increased reliability.

• LED Indicators: Each port has dedicated LED indicators for link status and activity, providing visual feedback on network connectivity. Additional LEDs indicate power status.

• Plug-and-Play: Its unmanaged nature means no software setup is required. Users simply connect their Ethernet devices (PLCs, HMIs, industrial PCs, sensors, etc.) to the switch ports, and it functions immediately.

Product Parameters

(Note: Always refer to the official AutomationDirect E-SW05U datasheet or manual for the most accurate and up-to-date specifications.)

• Model: E-SW05U

• Type: Unmanaged Industrial Ethernet Switch

• Number of Ports: 5

• Port Type: 10/100Base-TX (RJ45, Auto-MDI/MDI-X)

• Data Rate: 10 Mbps or 100 Mbps (Auto-negotiation)

• Duplex Mode: Half or Full Duplex (Auto-negotiation)

• Power Input: 12-48 VDC (typical range, check actual specs)

• Often features redundant power inputs (e.g., terminal block connections).

• Power Consumption: Low, typically < 2.5W (check actual specs).

• Housing: Metal (Aluminum or similar), IP30 rated.

• Mounting: 35mm DIN Rail Mountable.

• Operating Temperature: -10°C to 60°C (14°F to 140°F) (typical for industrial switches, verify exact range).

• Storage Temperature: -40°C to 85°C (-40°F to 185°F).

• Humidity: 10% to 90% RH, non-condensing.

• Dimensions (approx.): Typically very compact, e.g., 105mm (H) x 30mm (W) x 70mm (D) (verify exact dimensions).

• Certifications: CE, FCC (check for specific industrial certifications like UL/CSA if needed for your application).

Product Advantages

• Cost-Effective: Unmanaged switches are generally less expensive than managed switches, making them a budget-friendly option for network expansion.

• Ease of Use (Plug-and-Play): No configuration or software setup required, significantly simplifying installation and reducing commissioning time. Ideal for users with limited networking expertise.

• Industrial Hardened: Designed to withstand harsh industrial environments, including wide temperature ranges, electrical noise, and vibration, ensuring reliable operation.

• Compact Size: Its small form factor allows for installation in tight spaces within control panels or machinery.

• DIN Rail Mountable: Standard industrial mounting method for easy integration into existing control cabinets.

• Reliability: Redundant power inputs (if featured) enhance network uptime and reliability.

Precautions

• Power Supply: Ensure a stable and clean DC power supply within the specified voltage range. Connect redundant power inputs if available for increased reliability.

• Environmental Conditions: Install the switch within its specified operating temperature and humidity ranges. Avoid direct exposure to excessive dust, moisture, or corrosive substances. While IP30, it's not waterproof and should be in an appropriate enclosure.

• Cable Quality: Use high-quality industrial-grade Ethernet cables (e.g., Cat5e or Cat6) with proper shielding, especially in electrically noisy environments.

• Network Planning: While unmanaged, basic network planning is still important. Avoid creating network loops (though some switches have basic loop detection, it's not guaranteed). For larger or more complex networks, a managed switch might be more appropriate.

• Grounding: Ensure proper grounding of the switch and associated equipment to minimize electrical noise interference.

• Overloading: Do not exceed the maximum data throughput or number of connected devices that might overwhelm the switch's basic capabilities if high traffic is expected.

Product Applications

The AutomationDirect E-SW05U is suitable for various industrial applications where simple and reliable Ethernet connectivity is needed to connect a small number of devices.

• Small Industrial Control Panels: Expanding Ethernet connectivity for PLCs, HMIs, and small I/O blocks.

• Machine Builders: Integrating multiple Ethernet-enabled components within a single machine.

• Material Handling: Connecting barcode scanners, vision systems, and conveyors.

• Process Control: Linking sensors, actuators, and local control devices in smaller segments of a plant network.

• Building Automation: Providing network points for building management systems in a compact space.

• Distributed I/O: Connecting remote I/O modules to a central controller via Ethernet.

• Retrofit Projects: Easily adding Ethernet connectivity to older systems without complex network configuration.
