BAE CBI2410A DC Uninterruptible Power Supply

Product Parameters

The CBI2410A is part of the "Crompton Battery Interface" (CBI) series, specifically engineered for 24V systems.

Key Product Advantages

• Smart Battery Management: The device uses a sophisticated charging algorithm that monitors the battery's health and adjusts the charge accordingly. This prevents overcharging and significantly extends battery life.

• Automatic Multi-Stage Charging: It transitions seamlessly between recovery of deeply discharged batteries and maintenance (float) charging.

• Battery Diagnosis: It performs continuous internal resistance tests and checks for issues like "Battery Not Connected" or "Sulfated Battery," providing real-time status alerts via LED or dry contacts.

• Space Saving: By integrating the power supply and UPS controller, it reduces the footprint in the electrical cabinet by up to 50%.

• Power Boost: It can provide up to 2x the rated current for short periods to handle high inrush currents during motor starts or solenoid activations.

Important Considerations (Precautions)

• Ventilation: Ensure at least 20mm of clearance above and below the unit for natural convection cooling.

• Battery Selection: Ensure the jumper settings on the front panel match the specific chemistry of your battery (e.g., don't use a Lead-Acid profile for a Lithium battery).

• Temperature Compensation: For optimal battery life, it is highly recommended to use the external temperature sensor (RJ45 probe) to adjust charging voltage based on ambient heat.

• Reverse Polarity: Although protected by an internal fuse, always double-check battery polarity during installation to avoid damaging the unit or the fuse.

Common Applications

The CBI2410A is widely used in mission-critical environments where power failure is not an option:

1. Industrial Automation: Powering PLCs, HMIs, and sensors that must remain operational during a grid outage.

2. Fire Protection Systems: Ensuring fire pumps and alarm panels have a constant DC power source.

3. Telecommunications: Reliable backup for remote monitoring stations and radio equipment.

4. Security & Surveillance: Maintaining power for CCTV cameras and access control systems.

5. Smart Grids: Used in electrical substations for switchgear control and protection relays.
