Beckhoff C6920-1123-0050 Embedded PC

Beckhoff C6920-1123-0050 Embedded PC Overview

The Beckhoff C6920-1123-0050 is an industrial Embedded PC from Beckhoff Automation, designed for demanding automation and control tasks in various industrial environments. As part of Beckhoff's C69xx series, it typically offers a robust and compact design, high computing power, and industrial-grade reliability, making it suitable for applications ranging from machine control and visualization to data acquisition and communication gateways.

Product Detailed Description

• Core Functionality: The C6920-1123-0050 serves as a powerful and compact industrial computer. It is designed to run various operating systems (e.g., Windows Embedded Standard, Windows 10 IoT Enterprise, TwinCAT RTOS) and Beckhoff's TwinCAT automation software. This allows it to perform real-time control, HMI (Human Machine Interface) visualization, data logging, motion control, and communication tasks within a machine or plant.

• Design and Construction:

• Compact Industrial Housing: Typically features a robust metal housing (often aluminum) designed for direct cabinet mounting on a DIN rail or mounting plate.

• Fanless Operation: Many configurations of the C69xx series are fanless, making them highly reliable, maintenance-free, and suitable for dusty or harsh environments. This particular model (C6920) is known for being a fanless design.

• High Availability: Designed for 24/7 continuous operation in industrial settings.

• Industrial Components: Utilizes high-quality industrial-grade components for extended lifespan and reliability in challenging conditions.

• Connectivity and Interfaces:

• Ethernet Ports: Multiple Ethernet ports are standard for communication with industrial networks (e.g., EtherCAT, PROFINET, Ethernet/IP) and office networks.

• USB Ports: For connecting peripherals like keyboards, mice, and storage devices.

• Display Ports: DVI, DisplayPort, or VGA for connecting industrial monitors or HMI panels.

• Optional Interfaces: Often configurable with additional fieldbus interfaces (e.g., EtherCAT, CANopen, PROFIBUS) or serial ports (RS232/RS485) via optional modules or integrated ports.

• Operating System Support: Capable of running various Microsoft Windows operating systems optimized for embedded applications, as well as real-time operating systems for deterministic control.

Product Parameters

(These are typical parameters for a C6920 series PC. The exact values for C6920-1123-0050 would be specified by the "1123" and "0050" suffixes, which usually decode to CPU, RAM, storage, and specific I/O configuration. You must verify these with Beckhoff's official configurator or datasheet for the exact model.)

• Processor (CPU): Often an Intel Atom, Celeron, Core i3/i5/i7 (e.g., a specific Celeron or Core i3 for this series). The "1123" part likely indicates the specific CPU generation and model.

• RAM (Memory): Typically 2 GB, 4 GB, 8 GB, or 16 GB DDR3/DDR4 RAM (e.g., "1123" might imply 4 GB or 8 GB).

• Storage: Compact Flash (CFast) card or Solid State Drive (SSD) for operating system and application data. Sizes vary (e.g., 4 GB, 8 GB, 16 GB, 32 GB, 64 GB, 120 GB, etc.). The "0050" might indicate a specific storage size and type (e.g., 64 GB SSD).

• Operating System: Pre-installed Windows Embedded Standard, Windows 10 IoT Enterprise, or without OS for custom installations.

• Interfaces:

• Ethernet: Typically 2 x 10/100/1000BASE-T RJ45 ports.

• USB: 2-4 x USB 2.0 or USB 3.0 ports.

• Display: 1 x DVI-I (or similar).

• Optional: Serial (RS232/RS485), EtherCAT slave.

• Power Supply: 24 V DC (typical for industrial PCs).

• Cooling: Fanless (for the C6920 series).

• Protection Rating: Typically IP20 (for cabinet mounting), higher on the front if part of an HMI panel.

• Operating Temperature: Typically 0 °C to +55 °C (32 °F to 131 °F).

• Dimensions (W x H x D): Compact, varies slightly based on specific configuration.

• Mounting: DIN rail or mounting plate.

Product Advantages

• High Reliability & Durability: Fanless design, robust industrial components, and solid-state storage (SSD/CFast) minimize moving parts and increase resilience against vibration, shock, and dust. Ideal for harsh industrial environments.

• Compact Footprint: Space-saving design allows for easy integration into control cabinets, even those with limited space.

• Real-time Capabilities: When combined with TwinCAT automation software, it provides deterministic real-time control, making it suitable for demanding motion control and robotics applications.

• Scalable Performance: Available in various CPU and memory configurations, allowing users to select the right performance level for their specific application needs.

• Flexible Connectivity: Multiple standard and optional interfaces ensure seamless integration into diverse network architectures and with various field devices.

• Long-term Availability: Beckhoff typically ensures long-term availability of their industrial PC components.

• Integration with TwinCAT: Optimized for seamless integration with Beckhoff's TwinCAT automation software, offering a unified platform for PLC, Motion Control, HMI, and IoT functionalities.

Precautions

• Power Supply: Use a stable, regulated 24 V DC industrial power supply with sufficient current capacity. Observe correct polarity.

• Mounting: Mount the PC securely according to Beckhoff's instructions, ensuring proper ventilation (even for fanless units, heat dissipation through the casing is critical). Avoid mounting in direct sunlight or near strong heat sources.

• Environmental Conditions: Operate the PC within its specified temperature and humidity ranges. Avoid excessive dust, moisture, and corrosive gases.

• Grounding: Proper grounding is crucial for reliable operation and EMC compliance.

• Software Installation & Updates: Only install approved operating system images and software versions. Perform system and TwinCAT updates according to Beckhoff guidelines to ensure compatibility and stability.

• ESD Protection: Always observe electrostatic discharge (ESD) precautions when handling the PC, especially when installing or replacing components.

• Data Backup: Regularly back up the operating system, TwinCAT projects, and application data, especially before any significant changes or updates.

• Cooling (even fanless): Ensure adequate airflow around the unit, as fanless PCs rely on convection and the housing for heat dissipation. Do not block vents or restrict airflow.

Product Applications

The Beckhoff C6920 series Embedded PCs, including the C6920-1123-0050, are versatile and used in a wide array of industrial automation applications:

• Machine Control: As the central controller for packaging machines, printing machines, textile machines, woodworking machines, metalworking machines, and assembly lines.

• Process Control: In industries like chemical, pharmaceutical, food & beverage, for controlling batch processes, continuous processes, and plant automation.

• HMI and Visualization: Driving industrial monitors and touch panels for operator interaction and process visualization.

• Robotics and Motion Control: Providing precise and synchronized control for multi-axis robotic systems and complex motion sequences.

• Data Acquisition and Logging: Collecting process data from sensors and field devices for analysis, monitoring, and archiving.

• Building Automation: In large building management systems for controlling HVAC, lighting, and security.

• IoT Gateway/Edge Computing: Functioning as an edge device to collect, process, and transmit data to cloud platforms or higher-level IT systems.

• Renewable Energy: Control and monitoring systems for wind turbines, solar farms, and energy storage systems.
