Beckhoff ZK4530-0001-0008 EtherCAT Terminals

Beckhoff ZK4530-0001-0008 Overview

The Beckhoff ZK4530-0001-0008 is an EtherCAT Terminal, belonging to Beckhoff's EtherCAT Terminal series. Specifically, it is an 8-channel digital input terminal with diagnostic capabilities.

Product Detailed Description

• Function:

• The ZK4530-0001-0008 terminal is used to connect digital sensors or encoders from the field.

• It acquires 8 digital input signals and transmits these signals to a higher-level controller (such as a Beckhoff IPC or EtherCAT master) via the EtherCAT bus.

• This terminal module has integrated diagnostic functions that can detect and report faults such as wire breaks or short circuits.

• Each channel has an LED indicator to display its signal status.

• Features:

• 8 digital input channels.

• Wide input voltage range, suitable for different sensor types.

• Integrated diagnostic functions to improve system availability.

• LED status indication for each channel.

• Data transmission via the EtherCAT high-speed real-time bus.

• Compact terminal module design, saving control cabinet space.

• Supports hot-plugging (under certain conditions).

Product Parameters

• Number of Channels:

• 8 digital input channels

• Input Voltage Range:

• 24 V DC (-15% / +20%)

• Input Current:

• Typ. 7 mA / channel

• Input Filter Time:

• Configurable, e.g., 3 ms

• Connection Technology:

• Spring-loaded terminals

• Bus Interface:

• EtherCAT

• Current Consumption (Bus):

• Typ. 10 mA (5 V DC)

• Isolation Voltage:

• 500 V (bus/field potential)

• LED Indicators:

• One LED per channel (green, indicates signal status)

• One LED (red, indicates fault status)

• Diagnostic Functions:

• Wire break detection

• Short circuit detection

• Dimensions (W x H x D):

• 12 mm x 100 mm x 69 mm

• Weight:

• Approx. 55 g

• Protection Class:

• IP20

• Ambient Temperature (Operation):

• -25 °C to +60 °C

• Ambient Temperature (Storage):

• -40 °C to +85 °C

• Approvals:

• CE, UL/cUL

Product Advantages

• High Channel Density:

• Provides 8 digital input channels in a compact size, saving space and cost.

• Fast Real-Time Communication:

• Employs the EtherCAT bus for high-speed, real-time acquisition of digital signals.

• Integrated Diagnostics:

• Enables timely detection and reporting of wiring faults, improving system reliability and maintainability.

• Easy Installation and Wiring:

• Spring-loaded terminals allow for quick and easy wiring.

• Modular design facilitates easy expansion within the terminal block.

• High Reliability:

• Beckhoff, as a well-known automation product supplier, offers products with high quality and reliability.

• Flexible Configuration:

• Parameters such as input filter time can be configured to suit different application requirements.

Precautions

• Correct Wiring:

• Ensure correct wiring according to the wiring diagram to avoid short circuits or open circuits.

• Power Requirements:

• Ensure the supply voltage is within the specified range.

• Environmental Conditions:

• Avoid use in ambient temperatures and humidity levels exceeding the product specifications.

• ESD Protection:

• Observe electrostatic discharge (ESD) protection measures when handling the terminal module.

• Hot-Plugging Limitations:

• While EtherCAT supports hot-plugging, always consult the relevant manual for specific limitations and procedures before performing hot-plugging operations.

• Diagnostic Information Processing:

• The higher-level controller needs to be able to read and process diagnostic information from the terminal module for troubleshooting.

Product Applications

• Industrial Automation:

• Connecting signals from various digital sensors (e.g., proximity switches, photoelectric switches, limit switches).

• Acquiring digital output signals from encoders.

• Used in signal acquisition and control systems for various machines and equipment.

• Robotics:

• Connecting sensor signals on robot end-effectors.

• Used for input signal acquisition in robot control systems.

• Packaging Machinery:

• Acquiring sensor signals for detecting product position and status.

• Material Handling Systems:

• Acquiring sensor signals for conveyor belts and sorting systems.

• Other applications requiring high-speed, reliable acquisition of digital input signals.
