Panduit CJS5E88T Output module

Panduit Modules Overview

Panduit offers a wide range of modular products primarily used in electrical and network infrastructure. These modules are designed to provide flexibility, scalability, and reliability to meet various application needs. Depending on the specific product line, Panduit modules can include:

• Network Modules: e.g., Keystone Jack Modules, Fiber Optic Adapter Modules, Coupler Modules, etc., for data and telecommunications network connectivity.

• Electrical Modules: e.g., Terminal Block Modules, Fuse Holder Modules, Circuit Breaker Modules, etc., for electrical connections and protection.

• Cabinet and Cable Management Modules: e.g., Patch Panel Modules, Cable Manager Modules, etc., for organizing and managing cables within cabinets.

Due to the wide variety of Panduit modules, the following description will focus on common Network Keystone Jack Modules as an example. If you are interested in a specific type of Panduit module, please let me know, and I can provide more detailed information.

Product Detailed Description (as an example: Keystone Jack Modules)

• Function:

• Provides a connection point between network cables (e.g., Cat 5e, Cat 6, Cat 6A) and equipment.

•


• Terminates twisted pair cables to standard RJ45 interfaces.

• Supports data transmission.

• Features:

• Standard Keystone footprint for easy installation into various panels and patch panels.

• Multiple performance categories (Cat 5e, Cat 6, Cat 6A) to meet different network requirements.

• Utilizes reliable IDC (Insulation Displacement Connector) termination technology for quick termination without special tools. Some models may require a crimp tool.

• Available in shielded (STP) and unshielded (UTP) options.

• Various color-coding for easy identification and management.

Product Parameters (as an example: Keystone Jack Modules)

Due to the numerous models available, the following are some general parameters. Always refer to the official datasheet for the specific model:

• Performance Category:

• Cat 5e, Cat 6, Cat 6A

• Shielding Type:

• UTP (Unshielded Twisted Pair)

• STP (Shielded Twisted Pair)

• Interface Type:

• RJ45

• Termination Type:

• IDC (Insulation Displacement Connector)

• Cable Gauge:

• Supported cable AWG range (e.g., 22-26 AWG).

• Contact Material:

• e.g., Phosphor bronze with gold plating.

• Durability:

• Mating cycles (e.g., at least 750).

• IDC Termination Durability:

• Termination cycles (e.g., at least 200).

• Standards Compliance:

• e.g., TIA/EIA-568-C.2, ISO/IEC 11801.

• Operating Temperature:

• e.g., -10 °C to +60 °C.

Product Advantages (as an example: Keystone Jack Modules)

• Flexibility:

• Standard Keystone footprint allows for flexible installation in various panels and patch panels.

• Scalability:

• Easy to add or replace modules based on network requirements.

• Reliability:

• Utilizes high-quality materials and manufacturing processes to ensure reliable connections and data transmission.

• Ease of Installation:

• IDC termination technology simplifies the installation process.

• Performance Options:

• Available in different performance categories to meet various network bandwidth needs.

• Easy Management:

• Color-coding helps in identifying and managing network connections.

Precautions (as an example: Keystone Jack Modules)

• Correct Selection:

• Choose the appropriate performance category (Cat 5e, Cat 6, Cat 6A) based on network performance requirements (e.g., bandwidth needs).

• Select shielded or unshielded modules based on environmental and anti-interference requirements.

• Correct Installation:

• Follow Panduit's installation guidelines for termination, ensuring cables are properly inserted into IDC terminals and secured.

• Avoid excessive bending or pulling of cables.

• Use Appropriate Tools:

• Some IDC terminations may require the use of recommended crimp tools to ensure reliable connections.

• Follow Wiring Standards:

• Follow T568A or T568B wiring standards during termination.

• Environmental Conditions:

• Avoid using modules in environments exceeding their operating temperature range.

Product Applications (as an example: Keystone Jack Modules)

• Data Centers:

• Connections between servers, storage devices, and network equipment.

• Enterprise Networks:

• Connections for workstations, printers, VoIP phones, etc.

• Telecommunications Networks:

• Connection points for various communication equipment.

• Smart Buildings:

• Connecting various smart devices and systems.

• Industrial Networks:

• Connecting industrial control equipment.
