Pilz 312601 I/O Module

Product Details: Pilz 312601 (PSSu BP 1/8 C)

The Pilz 312601 is a base module component of the PSSuniversal system, which allows for flexible and scalable I/O (Input/Output) configurations.

• Manufacturer: Pilz

• Part Number (MPN): 312601

• Model Name: PSSu BP 1/8 C

• Product Type: Base Module for Electronic Module Periphery (I/O)

• Design: 1-row / 4 connection levels

• Connection Type: 8 x Cage-Clamp Terminals (spring-loaded connection)

• System Compatibility: PSSuniversal (designed for use with PSSuniversal I/O electronic modules for standard or safety applications).

⚙️ Product Parameters (Specifications)

✨ Product Advantages

• Flexibility and Scalability: As part of the modular PSSuniversal system, this base module allows for easy expansion and adaptation of the I/O configuration as system requirements change.

• Robust Connection: The use of Cage-Clamp Terminals (spring-loaded) ensures a reliable, vibration-proof, and maintenance-free electrical connection, which is crucial in industrial environments.

• Space-Saving Design: With a slim width of $12.6 \text{ mm}$, it contributes to a compact control cabinet layout.

• Simplified Wiring: The 4-level connection system on the base unit often simplifies the connection of sensors and actuators to the electronic module.

• Universal Application: Designed for both Standard and Failsafe (Safety) electronic modules, offering flexibility within the PSSuniversal system.

⚠️ Important Notes (Precautions)

1. System Integration: This product is a base module and is not a functional electronic component on its own. It requires a compatible PSSuniversal I/O electronic module (purchased separately) to function as an input or output device.

2. Installation: Installation should be performed by qualified personnel in compliance with all relevant safety and EMC (Electromagnetic Compatibility) regulations.

3. Correct Termination: Ensure that the correct wire sizes and proper stripping lengths are used to guarantee the integrity of the cage-clamp connection.

4. Environmental Conditions: While robust, the module must be operated within its specified environmental limits (e.g., temperature, humidity) to ensure reliable performance.
