Schneider 170AAI14000 Input Module

Schneider Modicon Momentum 170AAI14000 Overview

The Schneider Electric Modicon Momentum 170AAI14000 is an analog input module belonging to the Modicon Momentum series of I/O modules. It is designed to provide precise and reliable acquisition of analog signals for various industrial automation applications.

Product Detailed Description

• Function:

• Receives analog signals (e.g., voltage or current signals) from field devices.

• Converts these analog signals into digital signals for processing by Modicon controllers or other automation systems.

• Provides multiple analog input channels.

• Typically features configurable input ranges and filtering options.

• Features:

• 4 independent analog input channels.

• Configurable input types: Voltage (+/-10V, 0-10V) or Current (0-20mA, 4-20mA).

• High-resolution analog-to-digital conversion.

• Hot-swappable capability (in some configurations).

• LED indicators for module status and channel activity.

• Compact design for easy installation.

Product Parameters

• Number of Analog Input Channels:

• 4

• Input Types (Configurable):

• Voltage: +/-10V, 0-10V

• Current: 0-20mA, 4-20mA

• Resolution:

• Typically 12 bits or higher (refer to the specific datasheet)

• Accuracy:

• Refer to the specific datasheet

• Input Impedance:

• Voltage Input: Typically > 1 MΩ

• Current Input: Typically 250 Ω

• Conversion Time:

• Refer to the specific datasheet

• Supply Voltage:

• Typically 24 V DC (supplied by the backplane or controller)

• Current Consumption:

• Refer to the specific datasheet

• Isolation:

• Typically with channel-to-channel isolation or channel-to-logic isolation (refer to the specific datasheet)

• Connection Method:

• Pluggable screw terminal blocks

• Operating Temperature:

• Typically -25 °C to +70 °C

• Storage Temperature:

• Typically -40 °C to +85 °C

• Protection Rating:

• Typically IP20

• Dimensions:

• Compact Momentum module dimensions (refer to the specific datasheet)

• Weight:

• Refer to the specific datasheet

Product Advantages

• Versatility:

• Configurable voltage and current input types suitable for various sensors and field devices.

• High Accuracy:

• Provides precise and reliable acquisition of analog signals.

• Easy Integration:

• Designed for use with Modicon Momentum control systems, offering easy installation and configuration.

• Reliability:

• Schneider Electric is a well-known supplier of automation equipment with reliable product quality.

• Status Indication:

• LED indicators facilitate diagnosis of module and channel status.

• Hot-Swappable Capability:

• Supports hot-swapping in some configurations, facilitating maintenance and replacement.

Precautions

• Correct Wiring:

• Connect field devices and module terminals correctly according to the wiring diagram.

• Use appropriate cables and terminals.

• Select the Correct Input Type and Range:

• Configure the module's input channels according to the output signal type and range of the field devices.

• Power Requirements:

• Ensure that the power supply voltage meets the module's specifications.

• Environmental Conditions:

• Avoid using the module in environments exceeding its operating temperature and humidity ranges.

• EMC Compatibility:

• Follow EMC (Electromagnetic Compatibility) installation guidelines to ensure stable system operation.

• Refer to the Manual:

• Always read and follow the relevant product manual carefully before installing, configuring, and using the module.

Product Applications

• Industrial Automation:

• Analog signal acquisition in process control systems.

• Reading signals from temperature, pressure, flow, and other sensors.

• Data acquisition systems.

• Machine Control:

• Analog control signal input for servo drives or variable frequency drives.

• Acquisition of sensor feedback signals.

• Building Automation:

• Reading sensor signals in HVAC systems.

• Energy Management:

• Acquisition of analog data such as voltage and current.

• **Any application requiring the conversion of analog signals to digital signals.
