Schneider 170ADI35000 Input Module

Schneider Modicon Momentum 170ADI35000 Overview

The Schneider Modicon Momentum 170ADI35000 is an analog input module belonging to the Modicon Momentum series of I/O modules. It is designed to provide reliable and cost-effective analog signal acquisition for industrial automation applications.

Product Detailed Description

• Function:

• Receives analog signals (e.g., voltage or current signals) from field devices.

• Converts these analog signals into digital signals for processing by Modicon controllers (e.g., Momentum PLCs).

• Provides multiple analog input channels.

• Features:

• 8 single-ended or 4 differential analog input channels, software configurable.

• Configurable input ranges supporting various voltage and current signals (e.g., 0-10V, +/-10V, 0-20mA, 4-20mA).

• 12-bit resolution for precise analog signal conversion.

• Thermocouple and Resistance Temperature Detector (RTD) input capability (may require specific configuration or sub-models).

• Removable terminal blocks for easy wiring and maintenance.

• LED indicators for diagnostics and status indication.

• Compatible with Modicon Momentum PLCs and other Modbus-compliant devices.

Product Parameters

As the model number is very specific, the following provides typical parameters for Modicon Momentum analog input modules. Always refer to the official datasheet for the specific 170ADI35000 model:

• Number of Analog Input Channels:

• 8 single-ended or 4 differential

• Resolution:

• 12 bits

• Input Ranges (Configurable):

• Voltage: e.g., 0-10V, +/-10V, +/-5V, 1-5V

• Current: e.g., 0-20mA, 4-20mA

• Thermocouple/RTD: May support specific types (refer to manual)

• Input Impedance:

• Voltage Input: Typically > 1 MΩ

• Current Input: Typically 250 Ω

• Conversion Time:

• Conversion time per channel, refer to the manual for specific values.

• Accuracy:

• Accuracy within the specified temperature range, refer to the manual for specific values.

• Supply Voltage:

• Typically 24 V DC (range may vary)

• Power Consumption:

• Refer to the manual for specific values.

• Isolation:

• May provide isolation between channels or between channels and the logic side (refer to the manual).

• Wiring Method:

• Removable screw terminal blocks

• LED Indicators:

• Power, module status, channel status

• Operating Temperature:

• Typical range 0 °C to +60 °C

• Storage Temperature:

• Typical range -40 °C to +70 °C

• Humidity:

• Non-condensing humidity range, refer to the manual for specific values.

• Protection Rating:

• Typically IP20

• Dimensions and Weight:

• Refer to the manual for specific values.

• Standards Compliance:

• CE, UL, etc. (refer to the specific product manual)

Product Advantages

• Flexibility:

• Configurable channels and input ranges suitable for various analog signal types.

• Single-ended or differential input configurations to accommodate different signal sources and noise immunity requirements.

• High Accuracy:

• 12-bit resolution provides precise analog signal conversion.

• Ease of Use and Maintenance:

• Removable terminal blocks simplify wiring and replacement.

• LED indicators facilitate troubleshooting and status monitoring.

• Integration with Modicon Ecosystem:

• Seamless integration with Modicon Momentum PLCs and other Modbus devices.

• Cost-Effective:

• Provides an economical and practical solution for analog input applications.

Precautions

• Correct Wiring:

• Connect analog signal wires and power wires correctly according to the wiring diagram. Incorrect wiring may damage the module or lead to incorrect readings.

• Signal Integrity:

• Use shielded cables to reduce noise interference, especially for long-distance signal transmission.

• Ensure that the analog signal sources are within the module's input range.

• Power Requirements:

• Provide a stable power supply that meets the module's specifications.

• Environmental Conditions:

• Ensure that the operating environment temperature and humidity are within the module's allowable range.

• Avoid exposing the module to corrosive gases or excessive dust.

• Software Configuration:

• Use appropriate programming software (e.g., EcoStruxure Control Expert) to correctly configure the module's channel types and input ranges.

• Calibration:

• Depending on the application requirements, periodic calibration of the analog input module may be necessary to ensure accuracy.

Product Applications

• Industrial Automation:

• Acquisition of analog signals from sensors (e.g., temperature sensors, pressure sensors, flow meters).

• Process monitoring and control.

• Data acquisition systems.

• Building Automation:

• Monitoring temperature, pressure, and other parameters in HVAC systems.

• Water Treatment:

• Monitoring water quality parameters.

• Energy Management:

• Acquisition of analog data such as power and flow rates.

• Any application requiring the conversion of analog signals to digital signals for control or monitoring.
