Schneider TCSESM163F2CU0 Motion Controller

Schneider Electric TCSESM163F2CU0 Overview

The Schneider Electric TCSESM163F2CU0 is a Modicon PacDrive LMC058 Motion Controller. It is part of the Schneider Electric PacDrive 3 automation solution, designed to provide high performance and flexibility for complex motion control applications.

Product Detailed Description

• Function:

• Controls synchronous and asynchronous servo drives for high-precision motion control applications.

• Executes complex motion logic, including electronic cams, interpolation, positioning, etc.

• Communicates with other automation devices (such as HMI, I/O modules) via various communication interfaces.

• Supports multiple programming languages compliant with IEC 61131-3 standard.

• Offers integrated safety functions to meet machine safety requirements.

• Features:

• High-performance processor for fast control cycles and precise motion control.

• Integrated Ethernet interface supporting Modbus TCP/IP and Sercos III (for servo drive communication).

• CANopen interface for connecting field devices.

• USB interface for programming and diagnostics.

• SD card slot for program storage and data logging.

• Compact design for easy installation in control cabinets.

• Fanless design for increased reliability.

Product Parameters

• Product Range:

• Modicon PacDrive LMC058

• Model:

• TCSESM163F2CU0

• Processor:

• High-performance processor

• Program Memory:

• 2 MB

• Data Memory:

• 2 MB

• Communication Interfaces:

• Ethernet: 1 x RJ45 (Modbus TCP/IP, Sercos III)

• CANopen: 1 x RJ45

• USB: 1 x USB 2.0 (Type A)

• Serial Port: 1 x RS-232/RS-485

• I/O Handling Capacity:

• Up to 64 servo axes

• Control Cycle:

• Up to 1 ms

• Programming Languages:

• Compliant with IEC 61131-3 (LD, FBD, SFC, ST, IL)

• Safety Functions:

• Integrated safety function (Safe Torque Off - STO)

• Power Supply:

• 24 V DC

• Power Consumption:

• Typ. 10 W

• Protection Rating:

• IP20

• Operating Temperature:

• 0 °C to +55 °C

• Storage Temperature:

• -25 °C to +70 °C

• Dimensions (W x H x D):

• 100 mm x 130 mm x 60 mm

• Weight:

• Approx. 0.4 kg

• Certifications:

• CE, UL, cUL, EAC, etc. (refer to the specific product manual)

Product Advantages

• High-Performance Motion Control:

• Capable of handling complex motion control applications, achieving high precision and speed.

• Powerful Connectivity:

• Integrated multiple communication interfaces for easy integration with other automation devices.

• Flexible Programming:

• Supports multiple programming languages compliant with IEC 61131-3 for convenient user development.

• Integrated Safety Functions:

• Offers STO safety function, simplifying machine safety design.

• Compact and Reliable:

• Compact design saves space, and the fanless design increases reliability.

• Easy to Use and Maintain:

• Provided software tools and clear documentation facilitate user configuration, programming, and maintenance.

Precautions

• Correct Installation:

• Follow Schneider Electric's installation guidelines, ensuring the controller is installed in a suitable environment and properly grounded.

• Power Requirements:

• Use a 24 V DC power supply that meets the specifications.

• Environmental Conditions:

• Ensure the operating environment temperature and humidity are within the permissible range.

• Avoid strong vibrations and shocks.

• Software and Programming:

• Requires the use of Schneider Electric's SoMachine Motion or EcoStruxure Machine Expert software for programming and configuration.

• Safety Function Application:

• Correctly configure and test the integrated safety functions to ensure machine safety.

• Cable Connections:

• Use appropriate cables to connect the controller to servo drives, I/O modules, and other devices, and ensure reliable connections.

Product Applications

• Packaging Machinery:

• Precise motion control in high-speed filling, labeling, sealing, and other applications.

• Printing Machinery:

• Multi-axis synchronized control for high-quality printing.

• Machine Tools:

• Multi-axis linkage, high-speed cutting, and other applications.

• Material Handling:

• Precise motion control of robots and conveyors.

• Textile Machinery:

• High-speed, high-precision yarn control.

• **Other automation applications requiring complex motion control.
