SST SST-ESR2-CPX-P Communication Module

SST SST-ESR2-CPX-P Overview

The SST (Softing Industrial Automation GmbH) SST-ESR2-CPX-P is a communication module used to connect PROFIBUS DP networks and Ethernet networks. It typically functions as a data gateway between a PROFIBUS DP master or slave and Ethernet-based control or IT systems.

Product Detailed Description

• Function:

• Acts as a data gateway between PROFIBUS DP and Ethernet networks.

• Supports PROFIBUS DP master and slave functionality.

• Allows devices on the Ethernet network to access data on the PROFIBUS DP network, and vice versa.

• Typically supports various Ethernet protocols such as TCP/IP, UDP, HTTP, etc.

• Provides configuration and diagnostic interfaces.

• Features:

• Compact design for easy installation.

• Supports high-speed data transmission.

• Robust industrial housing.

• Easy to configure and manage.

• Provides status LEDs for easy diagnostics.

Product Parameters

As SST offers a variety of product models, and specific parameters may vary depending on the configuration, the following are some general features and parameters. Always refer to the official datasheet for the specific SST-ESR2-CPX-P model:

• Interfaces:

• PROFIBUS DP: DB9 connector, supports master or slave mode.

• Ethernet: RJ45 connector, supports 10/100 Mbps.

• Protocol Support:

• PROFIBUS DP (Master/Slave).

• Ethernet (TCP/IP, UDP, HTTP, etc.).

• May support other industrial Ethernet protocols such as PROFINET IO (depending on the specific model and firmware).

• Data Transmission Rate:

• PROFIBUS DP: Up to 12 Mbps.

• Ethernet: 10/100 Mbps.

• Power Supply:

• Typically 24 V DC.

• Power Consumption:

• Varies depending on the specific model.

• Operating Temperature:

• Typically -20 °C to +60 °C (varies by model).

• Protection Class:

• Typically IP20 or higher.

• Configuration Interface:

• Typically configured via the Ethernet interface and a web browser or dedicated configuration tool.

• Dimensions and Weight:

• Compact design, refer to the datasheet for specific dimensions and weight.

• Mounting:

• Typically DIN rail mounting.

Product Advantages

• Network Integration:

• Easily integrates PROFIBUS DP networks into Ethernet networks.

• Data Transparency:

• Enables seamless data transfer between different networks.

• Flexibility:

• Supports PROFIBUS DP master and slave modes, adapting to different application scenarios.

• Ease of Use:

• Provides user-friendly configuration and diagnostic tools.

• High Reliability:

• Robust industrial design ensures reliable operation in industrial environments.

Precautions

• Correct Installation:

• Follow SST's installation guidelines, ensuring the module is securely mounted and power and network cables are connected correctly.

• Power Requirements:

• Use a power supply that meets the specifications.

• Environmental Conditions:

• Ensure the operating environment temperature and humidity are within the permissible range.

• Network Configuration:

• Correctly configure the module's network parameters (IP address, subnet mask, etc.) and PROFIBUS DP parameters (address, baud rate, etc.).

• Firmware Updates:

• Regularly check and update the module's firmware for optimal performance and security.

• EMC Considerations:

• Take necessary electromagnetic compatibility (EMC) measures to reduce electromagnetic interference.

Product Applications

• Industrial Automation:

• Integrating PROFIBUS DP-based field devices into Ethernet-based control systems.

• Enabling data exchange between PLCs, HMIs, and other control systems.

• Process Control:

• Connecting PROFIBUS DP instrumentation and Ethernet networks.

• Factory Automation:

• Integrating different automation networks.

• Remote Monitoring and Diagnostics:

• Remotely accessing and diagnosing PROFIBUS DP devices via the Ethernet network.

• Data Acquisition and Analysis:

• Transferring PROFIBUS DP data to IT systems for analysis and reporting.
