HONEYWELL FC-TSHART-1620M HART Analog Input Module
Brand： Honeywell
Model number： FC-TSHART-1620M
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.5kg
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
HONEYWELL FC-TSHART-1620M HART Analog Input Module
Product Description
The Honeywell FC-TSHART-1620M is a high-performance HART (Highway Addressable Remote Transducer) analog input module designed for use in Honeywell’s Experion PKS and other distributed control systems (DCS). This module provides precise signal acquisition and processing for analog field devices, such as pressure, temperature, and flow transmitters, using the HART communication protocol. It enables real-time diagnostics and enhanced process visibility, making it ideal for modern industrial automation environments.
Product Specifications
| Parameter | Description |
|---|
| Model Number | FC-TSHART-1620M |
| Module Type | HART Analog Input Module |
| Channels | 16 single-ended or 8 differential analog input channels |
| Input Signal Range | 4–20 mA, HART compatible |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| HART Protocol | Supports HART Revision 5, 6, and 7 |
| Communication | HART multidrop capability (up to 2 devices per channel) |
| Update Rate | Programmable up to 10 Hz per channel |
| Isolation | Channel-to-channel and channel-to-bus isolation (1500 VAC) |
| Operating Temp. | -40°C to +70°C (-40°F to +158°F) |
| Power Consumption | 3.3 W (typical) |
| Certifications | CE, FM, CSA, ATEX, IECEx |
Product Advantages
Advanced Diagnostics: Enables real-time access to HART device diagnostics, improving predictive maintenance and reducing downtime.
Multidrop Support: Allows connection of multiple HART devices per channel, optimizing wiring and reducing installation costs.
High Accuracy: Delivers precise measurement with 16-bit resolution and ±0.1% accuracy.
Robust Isolation: Protects against ground loops and electrical noise, ensuring signal integrity.
Flexible Integration: Compatible with Honeywell Experion PKS and other DCS platforms.
Wide Temperature Range: Suitable for harsh industrial environments.
Global Certifications: Compliant with major international standards for safety and hazardous area use.
Precautions
Wiring Guidelines: Follow proper wiring practices to avoid signal interference and ensure correct grounding.
Configuration: Properly configure the module using Honeywell engineering tools to match field device parameters.
Environmental Limits: Do not exceed the operating temperature range or expose the module to excessive moisture or vibration.
HART Device Compatibility: Ensure connected field devices are HART-compatible and correctly addressed.
Firmware Updates: Use only approved Honeywell firmware updates to maintain compatibility and functionality.
Maintenance: Regularly inspect and clean module contacts and connectors to ensure reliable operation.
Product Applications
The Honeywell FC-TSHART-1620M is widely used in industries requiring high-precision analog input and HART communication capabilities, including:
Oil & Gas: Used in upstream and downstream processes for monitoring pressure, temperature, and flow in pipelines, separators, and compressors.
Chemical Processing: Provides critical input for reactor control, distillation columns, and material handling systems.
Power Generation: Monitors boiler and turbine parameters in fossil fuel and combined-cycle power plants.
Pharmaceuticals: Ensures precise environmental control and batch process monitoring.
Water & Wastewater: Manages flow and pressure in treatment plants and distribution systems.
Manufacturing: Integrates into production lines for process automation and quality control
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
