Siemens 6ES5420-4UA13 Digital Input Modules

Siemens SIMATIC S5 Digital Input Module SM 520 Overview

The Siemens SIMATIC S5 Digital Input Module SM 520 (Order No. 6ES5420-4UA13) is a component of the SIMATIC S5 Programmable Logic Controller (PLC) system. It is used to receive digital signals from field devices and transfer these signals to the PLC's CPU for processing.

Product Detailed Description

• Function:

• Receives digital input signals (e.g., 24V DC signals) from field devices such as sensors, switches, encoders.

• Converts the logic states ("0" or "1") of these input signals into internal signals that can be processed by the PLC.

• Provides electrical isolation to protect the PLC system from interference from field signals.

• Typically features input status indicator LEDs for easy diagnostics.

• Features:

• 8 digital input channels.

• Input voltage of 24V DC.

• Typical input current of 7 mA per channel.

• Optocoupler isolation for electrical isolation.

• Short input delay times for applications requiring fast response.

• Front connector for easy wiring.

• LEDs on the front of the module indicate the status of each input channel.

Product Parameters

• Order Number: 6ES5420-4UA13

• Product Name: SIMATIC S5, Digital Input Module SM 520

• Number of Input Channels: 8

• Input Voltage: 24 V DC

• Input Current: 7 mA/channel (typical)

• Input Delay Time:

• Low to High (0 to 1): Typ. 2.5 ms

• High to Low (1 to 0): Typ. 2.5 ms

• Electrical Isolation: Via optocouplers

• Isolation Voltage: 500 V AC

• Logic "0" Signal Voltage: -3 V DC to +5 V DC

• Logic "1" Signal Voltage: +15 V DC to +30 V DC

• Input Current Limitation: Approx. 15 mA per input channel

• Power Supply: Via backplane bus

• Power Consumption: Approx. 2 W

• Front Panel Indicators: One LED (green) per input channel for signal status indication

• Connection Method: Via front connector

• Dimensions (W x H x D): 25 mm x 130 mm x 80 mm (approx.)

• Weight: Approx. 120 g

• Ambient Temperature:

• Operating Temperature: 0 °C to +60 °C

• Storage Temperature: -25 °C to +70 °C

• Protection Class: IP20

• Standards Compliance: Complies with relevant SIMATIC S5 standards

Product Advantages

• High Reliability: Siemens SIMATIC S5 systems are known for their industrial reliability.

• Proven Technology: SIMATIC S5 is a mature and well-established PLC system.

• Easy Diagnostics: LEDs for each input channel facilitate troubleshooting.

• Electrical Isolation: Optocouplers provide good electrical isolation, protecting the PLC system.

• Fast Response: Short input delay times are suitable for applications requiring fast signal acquisition.

• Easy Wiring: Front connectors simplify the wiring of field devices.

• Integration with SIMATIC S5 System: Easy to integrate and configure as part of a SIMATIC S5 system.

Precautions

• For SIMATIC S5 Only: This module can only be used with Siemens SIMATIC S5 PLC systems.

• Follow Installation Guidelines: Ensure correct module installation and wiring according to Siemens' installation manual.

• Correct Input Voltage: Ensure the output signal voltage of field devices matches the module's input voltage specification (24V DC).

• Prevent Overload: Do not exceed the maximum permissible current per input channel.

• ESD Protection: Observe electrostatic discharge (ESD) protection measures when handling the module.

• Environmental Conditions: Ensure the operating environment temperature and humidity are within the module's specifications.

• Regular Inspection: Regularly check the module's connections and status indicators to ensure proper operation.

Product Applications

The Siemens SIMATIC S5 Digital Input Module SM 520 (6ES5420-4UA13) is typically used in various industrial automation applications to receive digital signals from field devices, such as:

• Sensor Signal Acquisition: Receiving signals from proximity switches, photoelectric sensors, limit switches, etc.

• Switch Status Monitoring: Monitoring the status of manual switches, relay contacts, etc.

• Encoder Signal Input: Receiving digital signals from incremental encoders for position or speed feedback.

• Process Control: Receiving digital status signals from field instruments.

• Machine Control: Receiving control command signals from operator panels or buttons.

• Automated Production Lines: Receiving digital signals from various automation equipment.
