Siemens 6ES5498-1AA41 Analog Input Measuring Range Module

Siemens 6ES5498-1AA41 (SIMATIC S5 Analog Input Measuring Range Module) Overview

The Siemens 6ES5498-1AA41 is a specific measuring range module designed for use with the Siemens SIMATIC S5 Programmable Logic Controller (PLC) system. Its primary function is to adapt the input range for analog input modules, allowing them to accurately process ±20 mA signals from various field devices. As part of the older S5 generation, this module is now a discontinued spare part.

Product Detailed Description

• Function: This module serves as a measuring range adapter for analog input modules within the SIMATIC S5 PLC system. It enables the analog input cards to correctly interpret and convert current signals in the range of ±20 mA from sensors and transmitters into digital values that the PLC can process. This is crucial for applications requiring precise current measurement in both positive and negative ranges.

• Application within S5 System: It plugs into or connects with existing SIMATIC S5 analog input modules, allowing them to handle a specific signal range (±20 mA) that might not be natively supported by the base module or to optimize the resolution for this particular range.

• Context: It is part of the extensive SIMATIC S5 product family, which was widely used in industrial automation for many years before being superseded by the SIMATIC S7 series.

Product Parameters

(Note: As a discontinued spare part, detailed technical specifications beyond basic identification are harder to find on current Siemens official channels. Information is primarily from third-party resellers or historical documentation.)

• Part Number: 6ES5498-1AA41

• Product Type: Measuring range module for analog inputs

• Signal Range: ±20 mA (for analog current inputs)

• System Compatibility: Siemens SIMATIC S5 PLC systems

• Net Weight: Approximately 0.013 kg (13 grams)

• Dimensions (Packaging): Approximately 11.9 cm x 12.7 cm x 1.8 cm

• Country of Origin: Germany

• Lifecycle Status: PM500: Discontinued Product or End of PLM & Support (Effective Date: October 1, 2022)

• RoHS Compliance: Product is not RoHS-compliant (contains lead).

Product Advantages (Historical Context)

• Signal Adaptation: Enabled SIMATIC S5 analog input modules to precisely handle ±20 mA signals, expanding their versatility.

• System Integration: Provided seamless integration within the robust and widely adopted SIMATIC S5 ecosystem.

• Reliability: As a Siemens product, it would have been designed for industrial reliability typical of the SIMATIC S5 series in its time.

• Cost-Effective (at the time): For existing S5 installations, these modules allowed for expansion or modification of analog input capabilities without requiring a full system upgrade.

Precautions

• Discontinued Product: The most significant precaution is that this product is discontinued and no longer supported by Siemens. This means:

• No official replacements are available.

• Future availability relies on surplus markets.

• No new firmware updates or official technical support from Siemens.

• Long-term system reliability might be compromised by reliance on unsupported parts.

• Compatibility: Ensure absolute compatibility with your specific SIMATIC S5 CPU and analog input module type before attempting to use this part.

• RoHS Non-Compliance: This module contains lead and is not RoHS-compliant. This is a crucial consideration for new designs or installations in regions with strict environmental regulations.

• ESD Protection: As with all electronic modules, handle with appropriate electrostatic discharge (ESD) precautions.

• Proper Installation: Refer to historical SIMATIC S5 documentation for correct installation procedures within the analog input module or rack.

Product Applications (Historical Context)

During its active lifecycle, the Siemens 6ES5498-1AA41 module would have been used in various industrial automation scenarios where the SIMATIC S5 PLC controlled processes involving analog current measurements.

• Process Control: In industries such as chemical, petrochemical, food & beverage, and pharmaceutical, for monitoring process variables like flow, pressure, temperature (from 2-wire or 4-wire transmitters that output ±20 mA).

• Manufacturing: For controlling and monitoring machinery where precise current measurements from sensors were required.

• Building Automation: Potentially in older building management systems that utilized S5 PLCs for monitoring and control of various parameters.

• Any Application with ±20 mA Transmitters: Wherever field devices outputted a ±20 mA current signal that needed to be read and processed by a SIMATIC S5 analog input card.
