Siemens 6ES5928-3UB11 Communications Processor

Siemens SIMATIC S5 CP 528 Communication ProcessorOrder No.: 6ES5928-3UB11

Overview

The Siemens SIMATIC S5 CP 528 is a communication processor (CP) used to connect SIMATIC S5 Programmable Logic Controllers (PLCs) to Industrial Ethernet networks. It enables S5 systems to exchange data with other Ethernet devices, facilitating functions such as monitoring, control, and data acquisition.

Product Detailed Description

• Function:

• Connects SIMATIC S5 PLCs to Industrial Ethernet networks.

• Supports TCP/IP and ISO-on-TCP protocols.

• Allows the S5 system to act as a server or client within the Ethernet network.

• Enables communication between the S5 PLC and HMIs (Human Machine Interfaces), SCADA (Supervisory Control and Data Acquisition) systems, programming devices, and other Ethernet-enabled devices.

• Supports data exchange, program upload/download, and remote diagnostics.

• Features:

• Plug-in module for the SIMATIC S5 series PLCs.

• Equipped with one RJ45 Ethernet interface.

• Supports 10/100 Mbit/s Ethernet speeds.

• Configuration and programming via configuration software.

• LED indicators display communication status and fault information.

• Compact design for easy integration into S5 systems.

Product Parameters

• Order Number: 6ES5928-3UB11

• Interface: 1 x RJ45 Ethernet interface (10/100 Mbit/s)

• Supported Protocols: TCP/IP, ISO-on-TCP

• PLC Interface: Connection to the I/O bus of the SIMATIC S5 PLC

• Power Supply: Supplied via the backplane bus of the S5 PLC

• Power Consumption: Dependent on the specific usage

• Ambient Temperature:

• Operating Temperature: 0 °C to +60 °C

• Storage Temperature: -25 °C to +70 °C

• Degree of Protection: IP20

• Dimensions (W x H x D): Standard S5 module dimensions

• Weight: Dependent on the specific module

• Compatible PLCs: SIMATIC S5 series PLCs

Product Advantages

• Ethernet Connectivity: Connects outdated SIMATIC S5 systems to modern Industrial Ethernet networks.

• Data Exchange: Enables data sharing and communication between the S5 PLC and other Ethernet devices.

• Remote Access: Allows for remote monitoring, diagnostics, and programming via Ethernet.

• System Integration: Facilitates the integration of S5 systems into broader automation architectures.

• Extends S5 System Lifespan: Extends the usability of existing S5 systems by providing modern communication capabilities.

• Cost-Effective: A more economical modernization solution compared to a complete replacement of the S5 system.

Precautions

• Correct Installation: Install the CP 528 module correctly into the rack of the S5 PLC according to Siemens' installation guidelines.

• Power Requirements: Ensure that the power supply of the S5 PLC can provide sufficient power for the CP 528.

• Ethernet Configuration: Properly configure the network parameters of the CP 528, such as IP address, subnet mask, and gateway.

• Software Configuration: Use the appropriate Siemens configuration software for programming and parameterizing the CP 528.

• Compatibility: Ensure that the firmware version of the CP 528 is compatible with the S5 PLC and other communication devices being used.

• Network Security: Consider potential network security risks and take appropriate security measures when connecting the S5 system to Ethernet.

Product Applications

• Modernization of Existing SIMATIC S5 Systems: Adding Ethernet communication capabilities to legacy S5 systems.

• Connection of S5 Systems to HMI/SCADA Systems: Enabling Ethernet communication for operator interfaces and monitoring systems.

• Data Acquisition from S5 Systems: Transferring process data from the S5 PLC to higher-level systems for analysis and storage via Ethernet.

• Remote Maintenance and Diagnostics of S5 Systems: Allowing engineers to remotely access and maintain S5 systems via Ethernet.

• Integration into Industry 4.0 Environments: Providing a foundation for connecting older automation systems to modern industrial networks.
