Siemens 6GF3420-0AA40 SR-P Optical Reader

Siemens SIMATIC MV420 SR-P Optical Reader (6GF3420-0AA40) Overview

The Siemens SIMATIC MV420 SR-P (6GF3420-0AA40) is a compact, high-performance optical reader designed for reliable and fast reading of both 1D and 2D codes in industrial environments. Part of the MV420 series, this model is characterized by its very high read speeds, making it suitable for demanding identification tasks in manufacturing and logistics. It includes advanced features like multicode reading, autotrigger, and ID-Genius for robust performance.

Product Detailed Description

• Functionality:

• 1D and 2D Code Reading: Capable of reading a wide range of 1D barcodes (e.g., Interleaved 2/5, Code 128, Code 39, EAN 13, EAN 8, UPC-A, UPC-E, GS1) and 2D codes (e.g., Data Matrix, Dot Code, PDF417, QR Code, Vericode).

• High Read Speeds: Designed for applications requiring very fast code acquisition, contributing to high throughput rates in automated systems.

• Multicode Reading: Can simultaneously read multiple codes within its field of view.

• Autotrigger: Automatically initiates reading when a code enters its detection area, simplifying integration.

• ID-Genius: An advanced decoding algorithm that enhances reading reliability, even with challenging or partially damaged codes.

• Integrated Illumination: Features an integrated ring light (red illumination) to ensure optimal lighting conditions for reading, regardless of ambient light.

• Design & Features:

• Compact Design: Its small form factor allows for flexible integration into tight spaces in machinery and production lines.

• Rugged Industrial Housing: IP67 protection class ensures robustness against dust and water ingress, making it suitable for harsh industrial environments.

• Fixed Focus Lens: Comes with a fixed focus lens, simplifying setup for a specific working distance.

• Communication Capabilities: Equipped with PROFINET IO, RS-422, and RS-232 interfaces for seamless integration with Siemens SIMATIC PLCs and other control systems.

Product Parameters

• Article Number: 6GF3420-0AA40

• Product Type: Optical Reader / Fixed Mount Barcode Scanner

• Series: SIMATIC MV420 SR-P (Performance model)

• Code Types Supported:

• 1D: Interleaved 2/5, Code 128, Code 39, EAN 13, EAN 8, UPC-A, UPC-E, GS1, etc.

• 2D: Data Matrix Code (DMC), Dot Code, PDF417 (without Truncated, Micro, and Macro), QR Code (without Micro and Macro), Vericode.

• Illumination: Integrated ring light (red illumination).

• Lens: M12 fixed focus lens.

• Supply Voltage: 19.2V DC - 28.8V DC (24V DC nominal).

• Power Consumption: (Typically low, specific value would be in datasheet).

• Interfaces:

• PROFINET IO

• RS-422

• RS-232

• Degree of Protection: IP67 (dust tight, protected against immersion up to 1m).

• Ambient Temperature: (Standard industrial range, typically 0°C to +50°C, exact value in datasheet).

• Net Weight: Approx. 0.377 kg.

• Dimensions: (Specific dimensions would be in the datasheet, but described as compact).

• Certifications: (Typically CE, UL, etc., detailed in the datasheet).

• Product Lifecycle Status: PM410: Product cancellation (since Oct 01, 2024). Successor: MV530 S.

Product Advantages

• High Performance: Very high read speeds ensure efficient operation in demanding, high-throughput applications.

• Robust Decoding: ID-Genius algorithm enhances reading reliability, even with challenging or sub-optimal codes.

• Versatile Code Reading: Supports a broad range of 1D and 2D codes, offering flexibility for various identification tasks.

• Seamless Integration: PROFINET IO and other standard interfaces allow for easy and direct integration into Siemens automation environments.

• Industrial Durability: IP67 rating ensures reliable operation in harsh industrial conditions, including exposure to dust and water.

• Compact Footprint: Its small size enables installation in tight spaces, maximizing machine design flexibility.

• Integrated Illumination: Built-in lighting simplifies setup and ensures consistent reading performance.

Precautions

• Product Discontinuation: Be aware that this product (6GF3420-0AA40) is cancelled since October 1, 2024, and is primarily available as a spare part. For new installations, consider its successor, the Siemens MV530 S.

• Firmware and Software Compatibility: Ensure compatibility with your existing SIMATIC PLC and engineering software (e.g., TIA Portal version).

• Correct Mounting and Alignment: Proper physical mounting and alignment of the reader with the codes are crucial for optimal reading performance. Ensure the code is within the reader's field of view and focus range.

• Lighting Conditions: While it has integrated illumination, optimize external lighting to avoid glare or reflections that could hinder reading.

• Power Supply: Provide a stable 24V DC power supply within the specified range.

• Cable Management: Use appropriate industrial-grade cables and ensure proper routing and strain relief for communication and power connections, especially in moving applications.

• Environmental Limits: Do not operate the device outside its specified temperature and humidity ranges.

• Maintenance: Periodically clean the optical window to prevent dust or debris from affecting reading performance.

Product Applications

The Siemens SIMATIC MV420 SR-P (6GF3420-0AA40) is well-suited for various industrial applications requiring fast and reliable code identification:

• Manufacturing & Production Lines:

• Component tracking and traceability.

• Quality control and defect detection (e.g., verifying part numbers).

• Assembly verification.

• Logistics & Warehousing:

• Automated material handling and sorting systems.

• Package and pallet identification.

• Inventory management.

• Automotive Industry:

• Tracking parts during engine assembly, chassis production, etc.

• Component verification for quality assurance.

• Electronics Manufacturing:

• PCB (Printed Circuit Board) and component traceability.

• Work-in-progress tracking.

• Packaging Industry:

• Verifying product codes and batch numbers on packaging.

• Ensuring correct product distribution.

• Robotics:

• Guiding robots for pick-and-place operations based on code identification.

• Tool identification on robotic arms.
