Siemens 6GK1543-0AA00 Communications Processors

Siemens SIMATIC NET CP 5431 FMS Communication Processor Overview

The Siemens SIMATIC NET CP 5431 FMS (Order No. 6GK1543-0AA00) is a communication processor used to connect SIMATIC S5 programmable logic controllers to Industrial Ethernet networks. It supports the FMS (Fieldbus Message Specification) protocol for data exchange between SIMATIC S5 systems and other devices.

Product Detailed Description

• Function:

• Provides an interface between SIMATIC S5 controllers and Industrial Ethernet networks.

• Supports the FMS (Fieldbus Message Specification) protocol for communication of process data and control commands.

• Allows SIMATIC S5 systems to exchange data with other FMS-capable devices (e.g., other SIMATIC controllers, HMI systems, PCs).

• Handles the functions of the Ethernet physical and data link layers.

• Connects the internal bus of the SIMATIC S5 to Ethernet.

• Features:

• For SIMATIC S5 programmable logic controllers.

• Connects to Industrial Ethernet via a 10Base-T Ethernet interface.

• Supports FMS master and slave functionality.

• Integrated communication function blocks for easy configuration and use in SIMATIC S5 programs.

• Configuration via STEP 5 programming software.

• Robust industrial design.

Product Parameters

• Order Number: 6GK1543-0AA00

• Interfaces:

• Ethernet: 1 x RJ45 port, 10Base-T

• SIMATIC S5 Bus Interface: For connection to the S5 backplane bus

• Protocol Support:

• FMS (Fieldbus Message Specification)

• Functions:

• FMS Master

• FMS Slave

• Data Transfer Rate:

• Ethernet: 10 Mbit/s

• Power Supply:

• Via SIMATIC S5 backplane bus

• Current Consumption:

• Please refer to the specific product manual

• Ambient Temperature:

• Operating Temperature: 0 °C to +60 °C

• Storage Temperature: -25 °C to +70 °C

• Degree of Protection:

• IP20

• Dimensions (W x H x D):

• Standard SIMATIC S5 module dimensions

• Weight:

• Please refer to the specific product manual

• Configuration Software:

• STEP 5 programming software

Product Advantages

• Integration into SIMATIC S5 Systems:

• Specifically designed for SIMATIC S5 controllers, ensuring easy integration and use.

• Supports Industrial Ethernet:

• Leverages the benefits of Industrial Ethernet for high-speed and reliable communication.

• Supports FMS Protocol:

• Enables standardized data exchange with various FMS-capable devices.

• Master and Slave Functionality:

• Can operate as an FMS master or slave in a network, providing flexible communication architectures.

• Easy Configuration:

• Configuration via the familiar STEP 5 programming software.

• Robust and Durable:

• Suitable for industrial environments.

Precautions

• Compatibility:

• Ensure compatibility with the SIMATIC S5 controller and Ethernet infrastructure being used.

• Correct Installation:

• Follow Siemens' installation guidelines to insert the CP 5431 FMS module into the correct slot on the SIMATIC S5 backplane bus.

• Power Requirements:

• Powered via the SIMATIC S5 backplane bus, ensure the S5 system has sufficient power supply.

• Ethernet Connection:

• Use appropriate Ethernet cables to connect to the Industrial Ethernet network.

• Configuration:

• Correctly configure the parameters of the CP 5431 FMS and FMS communication using STEP 5 programming software.

• FMS Configuration:

• Ensure all devices in the FMS network are correctly configured to communicate with each other.

• Environmental Conditions:

• Ensure the operating environment temperature is within the permissible range.

Product Applications

• Connecting SIMATIC S5 to Industrial Ethernet:

• Enables legacy SIMATIC S5 systems to participate in modern Industrial Ethernet communication.

• Communication with FMS-capable HMI Systems:

• Transfers process data to operator interfaces for visualization and control.

• Data Exchange with other SIMATIC Controllers:

• Enables data sharing between controllers in distributed control systems.

• Connection to SCADA Systems:

• Provides process data to supervisory control and data acquisition systems.

• Integration into Factory Automation Networks:

• Enables communication between SIMATIC S5 systems and other automation devices.
