ACS355-03E-04A1-4 ABB Output module

ABB ACS355-03E-04A1-4 Overview

The ABB ACS355 is a compact and general-purpose drive designed for machine builders, system integrators, and panel builders. The model ACS355-03E-04A1-4 indicates a three-phase input, IP20 protection class drive with an integrated EMC filter and a rated current of 4.1 A.

Product Detailed Description

• Function:

• Controls the speed and torque of three-phase AC induction motors.

• Provides programmable motor control functions to suit various application needs.

• Integrated Safe Torque Off (STO) function.

• Built-in braking chopper (on some models).

• Offers multiple control modes such as scalar control and vector control.

• Supports various fieldbus interfaces (via optional modules).

• Features a built-in PID controller.

• Features:

• Compact design for easy installation and commissioning.

• User-friendly interface and intuitive programming.

• Integrated EMC filter to meet electromagnetic compatibility requirements.

• Coated circuit boards for harsh environments.

• Flexible I/O configuration.

• Detachable terminal blocks.

Product Parameters

• Model: ACS355-03E-04A1-4

• Input Voltage: 3-phase, 380-480 V AC (-15% to +10%)

• Input Frequency: 50/60 Hz

• Rated Output Current (In): 4.1 A

• Rated Output Power (Pn):

• 380 V: 1.5 kW (2 hp)

• 480 V: 2.2 kW (3 hp)

• Overload Capability: 1.5 x In for 60 s, 1.8 x In for 2 s

• Protection Class: IP20

• EMC Filter: Built-in C3 class EMC filter

• Safety Function: Safe Torque Off (STO)

• Braking Chopper: Built-in

• Control Modes: Scalar (U/f), Vector (Sensorless Vector Control)

• I/O:

• 5 x Digital Inputs (DI)

• 2 x Analog Inputs (AI) (Voltage/Current selectable)

• 1 x Digital Output (DO)

• 1 x Analog Output (AO) (Current)

• 1 x Relay Output (RO)

• Communication Interface: RS-485 (Built-in Modbus RTU)

• Programming Unit: Built-in control panel, supports external control panel (optional)

• Ambient Temperature: -10 °C to +50 °C (no icing)

• Humidity: 5% to 95% RH (non-condensing)

• Mounting: Wall-mounted

• Dimensions (H x W x D): Please refer to the official ABB product manual

• Weight: Please refer to the official ABB product manual

• Certifications: CE, UL, cUL, CSA, EAC, RCM

Product Advantages

• Compact and Flexible: Space-saving design, easy to integrate into various applications.

• Easy to Use: Intuitive programming and commissioning, reducing installation and setup time.

• High Reliability: ABB's high-quality standards ensure reliable operation of the drive.

• Built-in Safety Function: STO function enhances machine safety.

• Integrated EMC Filter: Reduces external interference and simplifies installation.

• Multiple Control Modes: Suitable for various motors and application requirements.

• Built-in PID Controller: Simplifies process control applications.

• Wide Range of Applications: Suitable for numerous industrial and commercial applications.

Precautions

• Correct Installation: Follow ABB's installation manual to ensure the drive is installed in a well-ventilated area with appropriate ambient temperature.

• Electrical Connections: Ensure input and output power cables are connected correctly and reliably, and comply with local electrical codes.

• Motor Matching: Select a motor with rated current and power that matches the drive.

• Parameter Setting: Set the drive parameters correctly according to the specific motor and application requirements.

• Grounding: Ensure both the drive and the motor are properly grounded to prevent electric shock and reduce electromagnetic interference.

• Maintenance: Regularly check the operating status and cooling of the drive, and clean it as necessary.

• Safe Operation: Always disconnect the power supply to the drive before performing any operations or maintenance.

Product Applications

• Conveyors: Controlling the speed of conveyor belts.

• Fans and Pumps: Adjusting the flow rate of air and liquids.

• Textile Machines: Controlling the speed and tension of yarns.

• Ceramic Machines: Controlling the speed of kilns and forming machines.

• Woodworking Machines: Controlling the speed of tools and feeders.

• Food and Beverage Industry Machines: Controlling mixers, filling machines, etc.

• Packaging Machines: Controlling packaging speed and tension.

• Doors and Gates: Controlling the opening and closing speed of doors and gates.
