AB 1411-2SHT-201 Safety limit switch

Allen-Bradley 1411-2SHT-201 Overview

The Allen-Bradley 1411-2SHT-201 is a safety limit switch from the Bulletin 1411 series. These switches are designed to monitor the position of machine guarding (such as safety gates and guards) in industrial automation and machine safety applications. They provide reliable contact operation to help ensure the safety of personnel and equipment.

Product Detailed Description

• Function:

• Monitors the position of safety guarding (e.g., hinged safety doors, sliding guards).

• Triggers switch contacts through mechanical action when the safety guard is opened, interrupting the machine's power or initiating a safety interlock circuit.

• Provides safety contacts (typically Normally Closed - NC) that are closed when the safety guard is closed, allowing machine operation, and are forcibly opened when the safety guard is opened, stopping the machine or preventing it from starting.

• Forced guided contact design complies with safety standards, ensuring reliable opening of the safety circuit even in case of a fault.

• Features:

• Hinged safety switch designed for direct mounting on the hinge side of a safety gate.

• Compact design for easy installation in space-constrained areas.

• Rugged industrial housing to withstand harsh industrial environments.

• Available with multiple contact configurations to meet different safety circuit requirements.

• Complies with global safety standards such as ISO 14119.

Product Parameters

As specific parameters may vary depending on the configuration, the following are some general parameters for the Bulletin 1411 series safety limit switches. Always refer to the official datasheet for the specific 1411-2SHT-201 model:

• Contact Configuration:

• E.g., 2 NC (safety contacts).

• Rated Operating Voltage (Ue):

• E.g., 24 V AC/DC, 110 V AC, 230 V AC.

• Rated Operating Current (Ie):

• E.g., 3 A, 6 A.

• Degree of Protection (IP):

• E.g., IP66.

• Actuator Type:

• Hinged.

• Connection Method:

• E.g., screw terminals, cable entry.

• Standards Compliance:

• E.g., ISO 14119, IEC 60947-5-1.

• Housing Material:

• E.g., thermoplastic.

Product Advantages

• Integrated Safety Solution:

• Hinged design simplifies installation on safety gates without the need for separate actuators.

• High Reliability:

• Forced guided contacts ensure reliability in safety applications.

• Compact Design:

• Suitable for space-constrained applications.

• Robust and Durable:

• Suitable for industrial environments.

• Compliance with Global Safety Standards:

• Ensures adherence to international safety regulations.

• Easy Installation:

• Simple design facilitates easy installation.

Precautions

• Correct Selection:

• Choose the appropriate model based on specific safety requirements and gate design.

• Correct Installation:

• Follow Allen-Bradley's installation guidelines, ensuring the switch is securely mounted and correctly aligned with the door hinge.

• Safety Circuit Design:

• Integrate the safety limit switch into a safety circuit that complies with relevant safety standards.

• Regular Inspection and Testing:

• Regularly inspect the mechanical operation and electrical contacts of the switch, and perform functional tests to ensure proper operation.

• Prevent Misoperation:

• Ensure the switch cannot be accidentally triggered or blocked.

• Wiring:

• Connect the safety contacts and auxiliary contacts (if applicable) correctly according to the wiring diagram.

Product Applications

• Machine Safety:

• Monitoring the position of hinged safety doors.

• Used on guards for various industrial machinery and automation equipment.

• Packaging Machinery:

• Monitoring safety gates and interlocks.

• Food and Beverage Industry:

• Monitoring safety doors in hygienic areas.

• Pharmaceutical Industry:

• Monitoring safety doors in sterile environments.
