GE SFLA36AT0250 breaker

GE SFLA36AT0250 Overview

The GE SFLA36AT0250 is a Spectra™ Series Molded Case Circuit Breaker (MCCB). It is an electrical protection device designed to protect electrical circuits from overcurrent and short-circuit faults. The letters and numbers in the model name indicate its specific characteristics and ratings.

Product Detailed Description

• Function:

• Provides overload protection: trips when current exceeds a preset value for a sustained period.

• Provides short-circuit protection: trips quickly in the event of a sudden, high-magnitude fault current.

• Manual switching: can be used as a manual means to open and close an electrical circuit.

• Features:

• Spectra™ Series: GE's high-performance circuit breaker line.

• 3-Pole: for three-phase circuits.

• Thermal-Magnetic Trip Unit: uses a thermal element for overload protection and a magnetic element for short-circuit protection.

• Optional Accessories: such as auxiliary contacts, alarm contacts, undervoltage releases, shunt trips.

Product Parameters

Based on search results, here are the key parameters for the GE SFLA36AT0250:

• Frame Size:

• SFLA

• Ampere Rating:

• 250 A

• Number of Poles:

• 3

• Voltage Rating:

• 600V AC Maximum

• Interrupting Rating:

• AT (likely refers to a specific interrupting capacity level; refer to the official datasheet for the exact kA rating, typically ranging from 65kA to 100kA or higher)

• Trip Unit Type:

• Thermal-Magnetic

• Connection Type:

• May vary depending on the specific configuration (e.g., bolt-on).

• Standards:

• UL 489, CSA C22.2 No. 5

• For detailed and precise parameters, always refer to the official General Electric (GE) product datasheet for the SFLA36AT0250.

Product Advantages

• Reliable Overcurrent and Short-Circuit Protection:

• Effectively protects electrical equipment and circuits from damage.

• High-Performance Spectra™ Series:

• Offers superior performance and reliability.

• Suitable for Three-Phase Applications:

• 3-pole configuration is suitable for common three-phase power systems.

• Thermal-Magnetic Trip Unit:

• Provides reliable protection against different types of overcurrents.

• Optional Accessories:

• Allows customization based on specific application needs.

• Meets Industry Standards:

• Complies with important safety and performance standards such as UL and CSA.

Precautions

• Correct Selection:

• Ensure the circuit breaker's ampere rating, voltage rating, and interrupting rating match the application requirements.

• Correct Installation:

• Install according to national and local electrical codes and GE's installation instructions.

• Ensure all connections are tight and reliable.

• Regular Inspection:

• Periodically inspect the circuit breaker for any signs of damage or overheating.

• Qualified Personnel:

• Maintenance of the circuit breaker should be performed by qualified electrical personnel.

• Avoid Overloading:

• Do not exceed the circuit breaker's rated current.

Product Applications

• Power Distribution Systems:

• As a main circuit breaker or feeder breaker to protect downstream circuits.

• Industrial Equipment:

• Protection for motors, transformers, and other industrial machinery.

• Commercial Buildings:

• Used in electrical distribution panels for commercial buildings.

• OEM Applications:

• Integrated into various Original Equipment Manufacturer (OEM) equipment.
