Bently Nevada 3500/45 Overview
The Bently Nevada 3500/45 Position/Velocity Transducer Interface Module is a key component of the 3500 Monitoring System. It provides an interface for various position and velocity transducers and conditions the signals from these transducers into a format usable by the 3500 system.
Product Detailed Description
Function:
Accepts input signals from position transducers (e.g., LVDTs, eddy current probes) and velocity transducers (e.g., velocity pickups, accelerometers).
Provides the necessary power for these transducers.
Conditions transducer signals, including amplification, filtering, and linearization.
Converts the conditioned signals into a format usable by the 3500 Monitoring System.
Provides transducer fault detection and alarm capabilities.
Features:
Supports multiple channels per module (typically 4 or 6 channels).
Configurable input types and signal conditioning parameters to accommodate different transducers.
Integrated transducer health monitoring.
Seamless integration with other modules in the 3500 Monitoring System.
Configurable and monitorable through System 1 software.
Product Parameters
As there are different configurations and versions of the 3500/45 module, the following are some general parameters. Always refer to the official Bently Nevada datasheet for the specific model:
Product Advantages
Precautions
Product Applications
The Bently Nevada 3500/45 module is widely used for condition monitoring and protection of various rotating machinery, including but not limited to:
In these applications, the 3500/45 module is used to monitor critical parameters such as shaft position, vibration, and speed to provide early detection of potential mechanical failures, thereby preventing catastrophic damage and increasing equipment availability.
