ELAU MC-4/11/03/400 Servo controller

ELAU MC-4/11/03/400 Overview

The ELAU MC-4/11/03/400 is a compact servo controller belonging to the ELAU PacDrive series, a brand of Schneider Electric. PacDrive systems are known for their high performance, flexibility, and powerful capabilities in automation applications, particularly in packaging machinery. The MC-4/11/03/400 model features a specific configuration and characteristics suitable for applications requiring multi-axis synchronized control.

Product Detailed Description

• Function:

• Controls the motion of multiple servo axes, enabling precise synchronization and coordination.

• Executes complex motion control tasks such as electronic cams, interpolation, and synchronization.

• Integrated PLC functionality for executing machine logic control.

• Supports various communication interfaces for communication with higher-level controllers and other devices.

• Provides comprehensive diagnostics and monitoring functions.

• Features:

• Compact design, saving control cabinet space.

• High-performance processor for fast response and precise control.

• Integrated multiple servo axis control channels.

• Supports various feedback systems (e.g., encoders, resolvers).

• Programming environment based on IEC 61131-3 standard (SoMachine Motion).

Product Parameters

As the model number is very specific, the following parameters are based on a general understanding of the ELAU PacDrive MC-4 series. Always refer to the official datasheet for the specific MC-4/11/03/400 model:

• Number of Controlled Axes:

• 4 servo axes.

• Bus Interface:

• Sercos III (for real-time servo drive communication).

• PLC Programming Standard:

• IEC 61131-3.

• Programming Software:

• SoMachine Motion.

• Supply Voltage:

• 400 V DC (may vary depending on model suffix).

• Logic Interfaces:

• Digital inputs/outputs (quantity varies depending on the specific model).

• Analog inputs/outputs (quantity varies depending on the specific model).

• Feedback Interfaces:

• Supports various encoder types, such as incremental, absolute, SinCos.

• Ambient Temperature:

• Operating temperature range typically 0 °C to +50 °C.

• Protection Degree:

• Typically IP20.

• Dimensions (W x H x D):

• Compact dimensions, refer to the manual for specific measurements.

Product Advantages

• High-Performance Motion Control:

• Specifically designed for high-performance synchronized motion applications.

• Multi-Axis Synchronization:

• Enables precise synchronized control of multiple servo axes.

• Integrated PLC Functionality:

• Reduces the need for an additional PLC, simplifying the system architecture.

• Powerful Communication Capabilities:

• Sercos III provides high-speed, real-time communication with servo drives.

• Easy Programming and Configuration:

• SoMachine Motion offers a user-friendly programming environment.

• Compact Design:

• Saves space in the control cabinet.

Precautions

• Correct Installation:

• Follow Schneider Electric's installation guidelines, ensuring the controller is installed in a suitable control cabinet with proper heat dissipation.

• Power Connection:

• Ensure the power supply voltage matches the controller specifications and connect the power and ground wires correctly.

• Motor and Drive Compatibility:

• Ensure that the connected servo motors and drives are compatible with the MC-4/11/03/400.

• Software Configuration:

• Use SoMachine Motion software for correct programming and parameter configuration.

• Environmental Conditions:

• Avoid using the controller in environments exceeding its operating temperature and humidity ranges.

• Safe Operation:

• Observe relevant safety regulations during operation and maintenance.

Product Applications

• Packaging Machinery:

• Filling machines, labeling machines, sealing machines, palletizers, etc.

• Printing Machinery:

• Web presses, label presses, etc.

• Material Handling:

• Conveyor systems, robots, etc.

• Other Automation Fields:

• Applications requiring multi-axis synchronization and high-performance motion control.
