BENTLY 140482-01 Sensor Cable Assemblies

Bently Nevada 140482-01 Overview

The Bently Nevada 140482-01 is a Proximitor sensor cable assembly. It is used to connect Bently Nevada Proximitor sensors to monitoring instrumentation, such as the 3500 Monitoring System. This cable assembly is designed to provide reliable and accurate signal transmission in industrial environments.

Product Detailed Description

• Function:

• Transmits signals generated by the Proximitor sensor to the monitoring system.

• Provides the electrical connection between the sensor and the monitoring system.

• Ensures signal integrity, which is crucial for accurate vibration and position measurements.

• Features:

• Coaxial cable of a specific length with connectors on both ends.

• Connectors are designed to be compatible with Bently Nevada Proximitor sensors and monitoring systems.

• Rugged construction to withstand mechanical stress and chemical exposure in industrial environments.

• Shielded design to minimize electromagnetic interference (EMI) and radio frequency interference (RFI).

Product Parameters

As the 140482-01 is a cable assembly, its main parameters relate to the cable's length and connector types. The following are typical parameters; always refer to the specific order or product label for exact specifications:

• Model Number: 140482-01

• Length: Typically specified in feet or meters (e.g., 5 meters, 10 feet). This information is often part of a more complete part number variant.

• Connector A: Designed to connect to the Bently Nevada Proximitor sensor (typically an SMB or similar coaxial connector).

• Connector B: Designed to connect to the Bently Nevada monitoring system (typically an SMB or similar coaxial connector).

• Cable Type: Special coaxial cable with specific impedance and shielding characteristics to ensure signal integrity.

• Impedance: Typically 50 ohms or 75 ohms, depending on the application and sensor type.

• Shielding: Double or multiple layers of shielding to provide excellent EMI/RFI rejection.

• Temperature Range: Dependent on the cable jacket material, typically suitable for industrial temperature ranges (e.g., -40°C to +105°C).

• Jacket Material: E.g., Polyurethane, PTFE, offering abrasion, oil, and chemical resistance.

Product Advantages

• Reliable Signal Transmission: Specifically designed to ensure accurate signal transmission from the Proximitor sensor to the monitoring system.

• Compatibility with Bently Nevada Systems: Connectors and cable characteristics are fully compatible with Bently Nevada sensor and monitoring hardware.

• High Interference Immunity: Shielded design minimizes external electromagnetic interference, ensuring signal accuracy.

• Robust and Durable: Able to withstand harsh conditions in industrial environments, including mechanical stress and chemicals.

• Easy Installation: Plug-and-play design allows for quick connection of the sensor and monitoring system.

Precautions

• Select the Correct Length: Use a cable that meets the required length for the application, avoiding excessive or insufficient cable length.

• Proper Connection: Ensure that the cable connectors are securely attached to the corresponding ports on the sensor and monitoring system.

• Avoid Physical Damage: Prevent excessive bending, crushing, or abrasion of the cable.

• Environmental Conditions: Ensure that the cable's temperature and chemical exposure are within its specifications.

• Regular Inspection: Periodically inspect the cable and connectors for any signs of damage.

• Follow Bently Nevada Guidelines: Always adhere to Bently Nevada's recommendations for sensor cable installation and maintenance.

Product Applications

The Bently Nevada 140482-01 cable assembly is specifically used to connect:

• Bently Nevada Proximitor Sensors: Used for measuring shaft vibration, position, and speed on rotating machinery.

• Bently Nevada Monitoring Systems: Such as the 3500 Monitoring System, which receives and processes signals from the sensors for machine condition monitoring and protection.

Specific applications include:

• Turbomachinery: Steam turbines, gas turbines, compressors.

• Rotating Equipment: Motors, pumps, fans, gearboxes.

• Industrial applications requiring precise vibration and position monitoring.
