LENZE EVD532-E AC Drive

LENZE EVD532-E Overview

The LENZE EVD532-E is a compact AC frequency inverter from the 8400 motec series. This series is specifically designed for decentralized drive applications, allowing direct mounting on or near the motor, simplifying installation and reducing wiring. The EVD532-E provides precise speed and torque control and offers various functions to suit a wide range of industrial applications.

Product Detailed Description

• Function:

• Controls the speed and torque of three-phase AC induction motors.

• Designed for decentralized installation, close to the motor.

• Provides control for starting, stopping, acceleration, and deceleration.

• Supports V/f control mode.

• Integrated protection functions such as overcurrent, overvoltage, undervoltage, and overtemperature protection.

• Parameter setting and control via integrated interfaces.

• Features:

• Compact design, saving installation space.

• High degree of protection for industrial environments.

• Simple installation and commissioning.

• Integrated braking resistor.

• Optional fieldbus interfaces.

Product Parameters

As the LENZE EVD532-E may have different configurations and versions, the following are some typical parameters for the 8400 motec series inverters. Always refer to the official datasheet for the specific EVD532-E model:

• Power Range:

• Possibly between 0.37 kW and 7.5 kW (depending on the model).

• Voltage Class:

• 3 x 380-480 V AC (-15% / +10%).

• Output Frequency:

• 0 - 650 Hz.

• Control Mode:

• V/f control.

• Degree of Protection:

• IP65.

• Ambient Temperature:

• -10 °C to +55 °C (depending on installation location and model).

• Braking Resistor:

• Integrated.

• Communication Interfaces (Optional):

• CANopen, PROFIBUS DP, PROFINET IO, EtherCAT, EtherNet/IP.

• Overload Capacity:

• Varies by model.

• Digital Inputs/Outputs:

• Multiple programmable digital inputs and outputs.

• Analog Inputs/Outputs:

• Optional analog inputs and outputs.

Product Advantages

• Decentralized Installation:

• Reduces wiring effort and costs.

• Simplifies system design.

• Compact Design:

• Saves installation space, easy to integrate into machines.

• High Degree of Protection:

• Suitable for harsh industrial environments.

• Easy Installation and Commissioning:

• Simple connections and parameter settings.

• Integrated Braking Resistor:

• Convenient connection of braking resistors.

• Flexible Communication Options:

• Can be integrated into different control systems via various fieldbus interfaces.

Precautions

• Correct Selection:

• Choose the appropriate model based on motor power, load characteristics, and application requirements.

• Correct Installation:

• Follow LENZE's installation guidelines, ensuring the inverter is installed in a suitable location with adequate cooling.

• Correct Wiring:

• Connect the power supply, motor, and control signal lines correctly according to the wiring diagram, ensuring proper grounding.

• Parameter Settings:

• Set the inverter parameters correctly according to the specific motor and application requirements.

• EMC Considerations:

• Take necessary electromagnetic compatibility (EMC) measures to reduce electromagnetic interference.

• Safe Operation:

• Always follow relevant safety procedures when operating and maintaining the inverter.

• Regular Maintenance:

• Regularly check the inverter's operating status and cooling system, and perform necessary maintenance.

Product Applications

The LENZE EVD532-E inverter is suitable for various decentralized drive applications, including but not limited to:

• Conveyor Technology:

• Roller conveyors, belt conveyors.

• Material Handling:

• Hoists, cranes.

• Packaging Machinery:

• Filling machines, labeling machines.

• Food and Beverage Industry:

• Mixers, pumps.

• General Mechanical Engineering:

• Various equipment requiring decentralized drive control.
