Metso A413240 Locator

Metso (Valmet) A413240 Overview

The Metso (now Valmet) A413240 is a positioner used to control the opening and position of industrial process valves. The positioner receives a signal from the control system and precisely adjusts the position of the valve actuator based on this signal, thereby controlling the flow rate of fluids.

Product Detailed Description

• Function:

• Receives control signals from the control system (typically 4-20 mA current signals or digital signals).

• Converts the control signal into an output signal (typically a pneumatic signal) required to drive the valve actuator.

• Precisely controls the opening of the valve to achieve the desired fluid flow rate.

• Provides a feedback signal of the valve position to the control system.

• May include diagnostic functions for monitoring the performance of the valve and actuator.

• Features:

• Robust and durable design suitable for various industrial environments.

• High accuracy and high reliability.

• Easy to install, commission, and maintain.

• Configurable control characteristics to suit different application requirements.

• May support multiple communication protocols (e.g., HART, FOUNDATION Fieldbus, PROFIBUS PA).

Product Parameters

As Metso (Valmet) offers a wide range of product models, and specific parameters vary depending on the configuration, the following are some general parameters for positioners. Always refer to the official datasheet for the specific Metso (Valmet) A413240 model:

• Input Signal:

• 4-20 mA DC

• Digital communication protocols (HART, FOUNDATION Fieldbus, PROFIBUS PA, etc., depending on the model)

• Output Signal:

• Pneumatic signal (e.g., 0.2-1 bar, 0.4-2 bar, etc., depending on the model and supply air pressure)

• Supply Air Pressure:

• Wide range, e.g., 1.4 - 7 bar (20 - 100 psig), depending on the model.

• Ambient Temperature:

• Wide operating temperature range, e.g., -40 °C to +85 °C, depending on the model.

• Protection Degree:

• Typically IP66 or higher.

• Connections:

• Pneumatic connections: typically G1/4 or NPT 1/4.

• Electrical connections: vary depending on the model.

• Linearity:

• High accuracy, e.g., ±0.5% or better.

• Hysteresis:

• Low hysteresis, e.g., ≤ 0.5%.

• Vibration Resistance:

• Complies with industrial standards.

Product Advantages

• Precise Control:

• Enables precise control of valve opening, ensuring stable and efficient process operation.

• High Reliability:

• Robust design and high-quality components ensure reliable operation in harsh industrial environments.

• Ease of Use:

• Simple installation and commissioning process, convenient for users to operate and maintain.

• Configurability:

• Control parameters and characteristics can be configured according to different application requirements.

• Intelligent Functions:

• Some models may have advanced diagnostic functions to help monitor valve performance and predict potential problems.

• Compatibility:

• Can be used with various types of valves and actuators.

• Support for Multiple Communication Protocols:

• Facilitates integration into various control systems.

Precautions

• Correct Model Selection:

• Choose the appropriate positioner model based on the valve type, actuator characteristics, control signal requirements, and environmental conditions.

• Correct Installation:

• Follow the manufacturer's installation manual to ensure the positioner is correctly connected to the valve and actuator.

• Supply Air Quality:

• Use clean, dry compressed air as the air source to avoid damaging internal components of the positioner.

• Electrical Connections:

• Ensure electrical connections comply with relevant electrical safety standards and manufacturer requirements.

• Regular Maintenance:

• Regularly inspect and maintain the positioner, such as cleaning and lubrication, to ensure its normal operation.

• Parameter Setting:

• Set the parameters of the positioner correctly according to application requirements, such as control mode and travel range.

Product Applications

• Process Industries:

• Fluid control applications in oil and gas, chemical, pharmaceutical, pulp and paper, power generation, food and beverage, and other industries.

• HVAC (Heating, Ventilation, and Air Conditioning):

• Controlling valves in large air conditioning systems.

• Water Treatment:

• Controlling valves in water and wastewater treatment plants.

• Other Industrial Fields:

• Any industrial application requiring precise control of valve opening.

Shipping Port: Xiamen, China
