AutomationDirect EA3-T4CL control Panel

AutomationDirect EA3-T4CL Overview

The AutomationDirect EA3-T4CL is a compact Human Machine Interface (HMI) belonging to the C-more Micro series. It provides a cost-effective solution for visualizing and controlling various industrial automation applications. This model features a color touchscreen and supports communication with a wide range of PLCs and other control devices.

Product Detailed Description

• Function:

• Visualizes machine and process data.

• Allows operators to interact and control via the touchscreen.

• Communicates with PLCs and other automation devices through various communication protocols.

• Supports the creation of user interfaces including buttons, indicators, data displays, trend graphs, and alarm displays.

• Offers features such as recipe management, data logging, and multi-language support (depending on the specific model and firmware).

• Features:

• 4.3-inch TFT color touchscreen with a resolution of 480 x 272 pixels.

• LED backlight with adjustable brightness.

• One Ethernet port (10/100Base-T).

• One RS-232/RS-485 combination port.

• One USB programming port (Type B).

• Compact design for easy mounting on control panels.

• Programmed using the free C-more Micro engineering software.

Product Parameters

• Display:

• Size: 4.3 inches

• Type: TFT Color LCD

• Touchscreen: Analog Resistive

• Resolution: 480 x 272 pixels

• Brightness: Typ. 300 cd/m²

• Backlight: LED

• Power Supply:

• Rated Voltage: 24 V DC

• Permissible Range: 20.4 V DC to 27.6 V DC

• Power Consumption: Typ. 5 W

• Interfaces:

• Ethernet: 1 x RJ45 (10/100Base-T)

• Serial Port: 1 x RS-232/RS-485 (Terminal Block)

• Programming Port: 1 x USB 2.0 (Type B)

• Memory:

• User Program Memory: 3.2 MB

• User Data Memory: 512 KB

• Degree of Protection:

• Front: IP65F (for front mounting)

• Rear: IP20

• Ambient Temperature:

• Operating Temperature: 0 °C to +50 °C (32 °F to 122 °F)

• Storage Temperature: -20 °C to +60 °C (-4 °F to 140 °F)

• Dimensions ¹ (W x H x D):


  1. Fluke DPM3 Digital Pressure Meter - DPM III - Biotek Calibration

  microprecision.com

• 128 mm x 102 mm x 32 mm (5.04 in x 4.02 in x 1.26 in)

• Installation Cutout Dimensions (W x H):

• 119 mm x 93 mm (4.69 in x 3.66 in)

• Weight:

• Approx. 0.2 kg (0.44 lbs)

• Certifications:

• CE, UL (refer to the specific product manual)

Product Advantages

• Cost-Effective:

• Provides an affordable HMI solution with a color touchscreen and Ethernet connectivity.

• Easy to Use:

• Free and user-friendly C-more Micro engineering software simplifies project creation and configuration.

• Compact Design:

• Saves control panel space, suitable for applications with limited space.

• Versatile Communication Options:

• Supports Ethernet and serial communication for connecting to various PLCs and other devices.

• Reliability:

• Rugged industrial design suitable for industrial environments.

• Color Touchscreen:

• Provides clear and easy-to-understand visualization.

Precautions

• Correct Installation:

• Follow AutomationDirect's installation guidelines, ensuring the panel is securely mounted and properly grounded.

• Power Requirements:

• Use a 24 V DC power supply that meets the specifications.

• Environmental Conditions:

• Ensure the operating environment temperature and humidity are within the permissible range.

• Avoid strong vibrations and shocks.

• Engineering Software:

• Requires downloading and installing the free C-more Micro engineering software for project development.

• Cable Connections:

• Use appropriate cables to connect the HMI panel to PLCs and other devices, and ensure reliable connections.

• IP Protection Rating:

• While the front has an IP65F protection rating, the rear has a lower IP20 rating. Take care to protect the rear from dust and moisture ingress during installation.

Product Applications

The AutomationDirect EA3-T4CL HMI is suitable for a wide range of industrial automation applications, including but not limited to:

• Machine Control:

• Operator interface for small machines.

• Process Control:

• Monitoring and controlling simple industrial processes.

• Packaging Machinery:

• Setting operating parameters and displaying status.

• Material Handling:

• Controlling conveyors and simple automated equipment.

• HVAC (Heating, Ventilation, and Air Conditioning):

• System monitoring and control interface.

• Water Treatment:

• Monitoring simple water treatment equipment.
